Lu ng Boom/Jib - SPECIFICATIONS
108
Lu ng Boomwith Lu ng Lift Capacities
Full Counterweights (200,650 lbs) - Carbody weights (60,240 lbs)
Refer to notes on page 88- 89.
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
78.0
77.3
76.5
75.7
74.9
74.1
72.1
70.0
68.0
65.8
63.7
61.5
59.3
57.0
54.6
52.2
47.1
132,500
126,900
121,300
115,600
108,000
100,300
83,900
70,600
59,700
50,900
43,300
36,900
31,400
26,600
22,400
18,700
12,500
Load
Radius
(ft)
Boom
Angle
(deg.)
110 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
78.0
77.3
76.5
75.7
74.9
74.1
72.1
70.0
68.0
65.8
63.7
61.5
59.3
57.0
54.6
52.2
129,000
123,600
118,200
112,800
105,200
97,600
81,300
68,200
57,500
48,700
41,100
34,700
29,200
24,600
20,500
16,800
Load
Radius
(ft)
Boom
Angle
(deg.)
120 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
78.0
77.3
76.5
75.7
74.9
74.1
72.1
70.0
68.0
65.8
63.7
61.5
59.3
57.0
54.6
52.2
125,700
120,400
115,100
109,700
102,200
94,700
78,400
65,400
54,800
46,200
38,700
32,300
27,000
22,200
18,100
14,600
Load
Radius
(ft)
Boom
Angle
(deg.)
130 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
78.0
77.3
76.5
75.7
74.9
74.1
72.1
70.0
68.0
65.8
63.7
61.5
59.3
57.0
54.6
122,700
117,600
112,500
107,300
99,800
92,400
76,300
63,400
52,800
44,200
36,800
30,600
25,200
20,600
16,500
Load
Radius
(ft)
Boom
Angle
(deg.)
140 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
78.0
77.3
76.5
75.7
74.9
74.1
72.1
70.0
68.0
65.8
63.7
61.5
59.3
57.0
54.6
52.2
47.1
142,600
137,100
131,600
126,000
118,100
110,300
93,400
79,800
68,600
59,500
51,700
45,000
39,300
34,400
30,000
26,200
19,800
Load
Radius
(ft)
Boom
Angle
(deg.)
70 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
78.0
77.3
76.5
75.7
74.9
74.1
72.1
70.0
68.0
65.8
63.7
61.5
59.3
57.0
54.6
52.2
47.1
139,700
134,200
128,700
123,100
115,300
107,600
90,800
77,200
66,100
57,100
49,400
42,800
37,100
32,300
28,100
24,200
17,900
Load
Radius
(ft)
Boom
Angle
(deg.)
80 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
78.0
77.3
76.5
75.7
74.9
74.1
72.1
70.0
68.0
65.8
63.7
61.5
59.3
57.0
54.6
52.2
47.1
137,900
132,000
126,200
120,300
112,500
104,800
88,200
74,800
63,700
54,800
47,100
40,400
34,900
30,100
25,900
22,100
15,900
Load
Radius
(ft)
Boom
Angle
(deg.)
90 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
78.0
77.3
76.5
75.7
74.9
74.1
72.1
70.0
68.0
65.8
63.7
61.5
59.3
57.0
54.6
52.2
47.1
134,900
129,600
124,200
118,700
111,000
103,300
86,700
73,300
62,400
53,400
45,800
39,300
33,600
28,800
24,600
20,900
14,700
Load
Radius
(ft)
Boom
Angle
(deg.)
100 ft Jib
360
ﾟ
Rated Load
(lbs)
150' Boom
150' Boom
6
Reeves
6
Reeves
6
Reeves
6
Reeves
6
Reeves
6
Reeves
6
Reeves
6
Reeves
