Lu ng Boom/Jib - SPECIFICATIONS
110
Lu ng Boomwith Lu ng Lift Capacities
Full Counterweights (200,650 lbs) - Carbody weights (60,240 lbs)
Refer to notes on page 88- 89.
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
78.8
78.1
77.3
76.6
75.8
75.1
73.2
71.3
69.4
67.5
65.5
63.5
61.4
59.3
57.2
55.0
50.4
132,000
125,500
119,100
112,600
105,900
99,200
83,900
70,600
59,700
50,900
43,200
36,700
31,100
26,400
22,200
18,500
12,100
Load
Radius
(ft)
Boom
Angle
(deg.)
110 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
78.8
78.1
77.3
76.6
75.8
75.1
73.2
71.3
69.4
67.5
65.5
63.5
61.4
59.3
57.2
55.0
128,500
122,200
116,000
109,700
103,100
96,400
81,300
68,200
57,500
48,700
41,100
34,700
29,200
24,400
20,200
16,500
Load
Radius
(ft)
Boom
Angle
(deg.)
120 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
78.8
78.1
77.3
76.6
75.8
75.1
73.2
71.3
69.4
67.5
65.5
63.5
61.4
59.3
57.2
55.0
125,400
119,200
112,900
106,600
100,100
93,500
78,400
65,400
54,800
46,200
38,700
32,300
27,000
22,200
18,000
14,400
Load
Radius
(ft)
Boom
Angle
(deg.)
130 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
78.8
78.1
77.3
76.6
75.8
75.1
73.2
71.3
69.4
67.5
65.5
63.5
61.4
59.3
57.2
121,800
115,900
110,100
104,200
97,700
91,200
76,300
63,400
52,800
44,200
36,800
30,600
25,200
20,600
16,500
Load
Radius
(ft)
Boom
Angle
(deg.)
140 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
120.0
78.8
78.1
77.3
76.6
75.8
75.1
73.2
71.3
69.4
67.5
65.5
63.5
61.4
59.3
57.2
55.0
50.4
45.4
142,100
135,600
129,200
122,700
115,800
108,900
93,200
79,600
68,400
59,300
51,500
44,800
39,100
34,200
29,800
26,000
19,400
14,300
Load
Radius
(ft)
Boom
Angle
(deg.)
70 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
78.8
78.1
77.3
76.6
75.8
75.1
73.2
71.3
69.4
67.5
65.5
63.5
61.4
59.3
57.2
55.0
50.4
139,800
133,200
126,500
119,900
113,000
106,200
90,500
77,000
66,100
57,000
49,200
42,600
36,900
32,000
27,700
24,000
17,400
Load
Radius
(ft)
Boom
Angle
(deg.)
80 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
78.8
78.1
77.3
76.6
75.8
75.1
73.2
71.3
69.4
67.5
65.5
63.5
61.4
59.3
57.2
55.0
50.4
137,200
130,800
124,300
117,900
111,100
104,300
88,900
75,500
64,400
55,300
47,700
41,100
35,300
30,600
26,300
22,400
15,900
Load
Radius
(ft)
Boom
Angle
(deg.)
90 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
78.8
78.1
77.3
76.6
75.8
75.1
73.2
71.3
69.4
67.5
65.5
63.5
61.4
59.3
57.2
55.0
50.4
134,000
127,800
121,700
115,500
108,700
101,900
86,500
73,300
62,400
53,400
45,700
39,100
33,600
28,700
24,400
20,700
14,300
Load
Radius
(ft)
Boom
Angle
(deg.)
100 ft Jib
360
ﾟ
Rated Load
(lbs)
160' Boom
160' Boom
6
Reeves
6
Reeves
6
Reeves
6
Reeves
6
Reeves
6
Reeves
6
Reeves
6
Reeves
