Lu ng Boom/Jib - SPECIFICATIONS
111
Lu ng Boomwith Lu ng Lift Capacities
Full Counterweights (200,650 lbs) - Carbody weights (60,240 lbs)
Refer to notes on page 88- 89.
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
78.8
78.1
77.3
76.6
75.8
75.1
73.2
71.3
69.4
67.5
65.5
63.5
61.4
107,000
102,000
97,000
91,900
85,600
79,300
64,900
52,500
42,400
34,100
27,000
20,900
15,700
Load
Radius
(ft)
Boom
Angle
(deg.)
190 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
78.8
78.1
77.3
76.6
75.8
75.1
73.2
71.3
69.4
67.5
65.5
102,700
98,000
93,300
88,600
82,300
76,100
61,900
49,600
39,600
31,200
24,200
Load
Radius
(ft)
Boom
Angle
(deg.)
200 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
78.8
78.1
77.3
76.6
75.8
75.1
73.2
71.3
69.4
67.5
65.5
63.5
61.4
59.3
57.2
121,100
115,000
109,000
102,900
96,500
90,000
75,200
62,300
51,700
43,100
36,200
30,600
25,200
20,600
16,500
Load
Radius
(ft)
Boom
Angle
(deg.)
150 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
78.8
78.1
77.3
76.6
75.8
75.1
73.2
71.3
69.4
67.5
65.5
63.5
61.4
59.3
57.2
117,300
112,100
106,900
101,600
95,100
88,700
73,900
61,000
50,600
42,000
34,600
28,400
23,000
18,400
14,400
Load
Radius
(ft)
Boom
Angle
(deg.)
160 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
78.8
78.1
77.3
76.6
75.8
75.1
73.2
71.3
69.4
67.5
65.5
63.5
61.4
59.3
114,000
108,700
103,400
98,100
91,700
85,300
70,700
57,900
47,500
39,000
31,700
25,500
20,300
15,700
Load
Radius
(ft)
Boom
Angle
(deg.)
170 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
78.8
78.1
77.3
76.6
75.8
75.1
73.2
71.3
69.4
67.5
65.5
63.5
61.4
59.3
110,000
105,100
100,300
95,400
89,100
82,800
68,300
55,700
45,300
37,000
29,800
23,500
18,300
13,900
Load
Radius
(ft)
Boom
Angle
(deg.)
180 ft Jib
360
ﾟ
Rated Load
(lbs)
160' Boom
160' Boom
6
Reeves
6
Reeves
4
Reeves
4
Reeves
4
Reeves
4
Reeves
