Lu ng Boom/Jib - SPECIFICATIONS
113
Lu ng Boomwith Lu ng Lift Capacities
Full Counterweights (200,650 lbs) - Carbody weights (60,240 lbs)
Refer to notes on page 88- 89.
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
79.5
78.8
78.1
77.4
76.7
76.0
74.2
72.5
70.7
68.9
67.0
65.2
63.3
106,500 *
99,000 *
91,400 *
84,000
80,200
76,400
65,100
52,700
42,600
34,300
27,200
21,100
15,900
Load
Radius
(ft)
Boom
Angle
(deg.)
190 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
79.5
78.8
78.1
77.4
76.7
76.0
74.2
72.5
70.7
68.9
67.0
65.2
63.3
102,400 *
95,100 *
87,900 *
80,700
76,900
73,100
62,000
49,900
39,800
31,600
24,600
18,500
13,500
Load
Radius
(ft)
Boom
Angle
(deg.)
200 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
79.5
78.8
78.1
77.4
76.7
76.0
74.2
72.5
70.7
68.9
67.0
65.2
63.3
61.3
59.4
120,400 *
112,500 *
104,500 *
96,600
92,400
88,300
76,400
63,600
53,100
44,400
36,900
30,600
25,200
20,600
16,500
Load
Radius
(ft)
Boom
Angle
(deg.)
150 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
79.5
78.8
78.1
77.4
76.7
76.0
74.2
72.5
70.7
68.9
67.0
65.2
63.3
61.3
59.4
116,800 *
109,100 *
101,300 *
93,700
89,600
85,500
73,800
61,200
50,600
42,000
34,600
28,400
23,000
18,400
14,400
Load
Radius
(ft)
Boom
Angle
(deg.)
160 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
79.5
78.8
78.1
77.4
76.7
76.0
74.2
72.5
70.7
68.9
67.0
65.2
63.3
61.3
113,300 *
105,500 *
97,800 *
90,200
86,200
82,100
70,600
58,200
47,800
39,300
32,000
25,800
20,500
16,000
Load
Radius
(ft)
Boom
Angle
(deg.)
170 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
79.5
78.8
78.1
77.4
76.7
76.0
74.2
72.5
70.7
68.9
67.0
65.2
63.3
61.3
109,400 *
102,100 *
94,800 *
87,600
83,700
79,800
68,400
56,000
45,500
37,200
30,000
23,800
18,600
14,100
Load
Radius
(ft)
Boom
Angle
(deg.)
180 ft Jib
360
ﾟ
Rated Load
(lbs)
170' Boom
170' Boom
6
Reeves
6
Reeves
4
Reeves
4
Reeves
4
Reeves
4
Reeves
