Lu ng Boom/Jib - SPECIFICATIONS
119
Lu ng Boomwith Lu ng Lift Capacities
Full Counterweights (200,650 lbs) - Carbody weights (60,240 lbs)
Refer to notes on page 88- 89.
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
79.3
78.7
78.1
76.7
75.2
73.7
72.2
70.7
69.1
67.6
66.0
82,000 *
77,400 *
72,700 *
62,500
53,700
45,100
37,100
29,900
23,500
18,300
13,800
Load
Radius
(ft)
Boom
Angle
(deg.)
180 ft Jib
360
ﾟ
Rated Load
(lbs)
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
79.3
78.7
78.1
76.7
75.2
73.7
72.2
70.7
69.1
67.6
78,700 *
74,100 *
69,400 *
59,300
50,600
42,200
34,300
27,100
20,900
15,700
Load
Radius
(ft)
Boom
Angle
(deg.)
190 ft Jib
360
ﾟ
Rated Load
(lbs)
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
79.3
78.7
78.1
76.7
75.2
73.7
72.2
70.7
69.1
67.6
75,400 *
70,900 *
66,400 *
56,400
47,800
39,500
31,800
24,700
18,500
13,500
Load
Radius
(ft)
Boom
Angle
(deg.)
200 ft Jib
360
ﾟ
Rated Load
(lbs)
200' Boom
4
Reeves
4
Reeves
4
Reeves
