Lu ng Boom/Jib - SPECIFICATIONS
114
Lu ng Boomwith Lu ng Lift Capacities
Full Counterweights (200,650 lbs) - Carbody weights (60,240 lbs)
Refer to notes on page 88- 89.
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
78.1
77.5
76.8
75.1
73.5
71.8
70.1
68.4
66.6
64.9
63.1
61.3
59.4
102,100
97,700
93,400
81,900
70,200
59,300
50,400
42,800
36,200
30,500
25,900
21,700
17,800
Load
Radius
(ft)
Boom
Angle
(deg.)
110 ft Jib
360
ﾟ
Rated Load
(lbs)
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
78.1
77.5
76.8
75.1
73.5
71.8
70.1
68.4
66.6
64.9
63.1
61.3
59.4
99,500
95,200
90,800
79,500
67,800
57,100
48,200
40,700
34,200
28,500
23,900
19,700
15,900
Load
Radius
(ft)
Boom
Angle
(deg.)
120 ft Jib
360
ﾟ
Rated Load
(lbs)
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
78.1
77.5
76.8
75.1
73.5
71.8
70.1
68.4
66.6
64.9
63.1
61.3
59.4
98,100
93,900
89,700
78,500
66,900
56,200
47,300
39,800
33,400
27,800
23,200
19,000
15,200
Load
Radius
(ft)
Boom
Angle
(deg.)
130 ft Jib
360
ﾟ
Rated Load
(lbs)
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
78.1
77.5
76.8
75.1
73.5
71.8
70.1
68.4
66.6
64.9
63.1
61.3
95,900
91,700
87,500
76,400
65,000
54,400
45,600
38,000
31,600
26,100
21,600
17,500
Load
Radius
(ft)
Boom
Angle
(deg.)
140 ft Jib
360
ﾟ
Rated Load
(lbs)
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
120.0
78.1
77.5
76.8
75.1
73.5
71.8
70.1
68.4
66.6
64.9
63.1
61.3
59.4
55.6
51.5
112,700
108,100
103,500
91,700
79,600
68,400
59,300
51,500
44,800
38,900
34,000
29,500
25,500
19,000
13,600
Load
Radius
(ft)
Boom
Angle
(deg.)
70 ft Jib
360
ﾟ
Rated Load
(lbs)
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
78.1
77.5
76.8
75.1
73.5
71.8
70.1
68.4
66.6
64.9
63.1
61.3
59.4
55.6
110,000
105,500
101,000
89,300
77,200
66,100
57,100
49,300
42,600
36,700
31,900
27,500
23,500
17,000
Load
Radius
(ft)
Boom
Angle
(deg.)
80 ft Jib
360
ﾟ
Rated Load
(lbs)
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
78.1
77.5
76.8
75.1
73.5
71.8
70.1
68.4
66.6
64.9
63.1
61.3
59.4
55.6
107,400
102,900
98,500
86,800
74,800
63,900
54,900
47,100
40,400
34,700
29,900
25,500
21,500
15,000
Load
Radius
(ft)
Boom
Angle
(deg.)
90 ft Jib
360
ﾟ
Rated Load
(lbs)
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
78.1
77.5
76.8
75.1
73.5
71.8
70.1
68.4
66.6
64.9
63.1
61.3
59.4
55.6
105,000
100,500
96,100
84,600
72,800
61,700
52,800
45,200
38,600
32,700
28,100
23,800
19,800
13,500
Load
Radius
(ft)
Boom
Angle
(deg.)
100 ft Jib
360
ﾟ
Rated Load
(lbs)
180' Boom
180' Boom
4
Reeves
4
Reeves
4
Reeves
4
Reeves
4
Reeves
4
Reeves
4
Reeves
4
Reeves
