Lu ng Boom/Jib - SPECIFICATIONS
106
Lu ng Boomwith Lu ng Lift Capacities
Full Counterweights (200,650 lbs) - Carbody weights (60,240 lbs)
Refer to notes on page 88- 89.
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
77.2
76.3
75.5
74.6
73.8
72.9
70.7
68.5
66.3
64.0
61.6
59.2
56.8
54.2
51.6
48.9
43.0
143,600
134,300
124,900
115,600
108,000
100,300
83,900
70,600
59,700
50,900
43,300
36,900
31,400
26,600
22,400
18,800
12,700
Load
Radius
(ft)
Boom
Angle
(deg.)
110 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
77.2
76.3
75.5
74.6
73.8
72.9
70.7
68.5
66.3
64.0
61.6
59.2
56.8
54.2
51.6
48.9
140,500
131,300
122,000
112,800
105,200
97,600
81,300
68,200
57,300
48,600
41,100
34,700
29,200
24,600
20,500
16,800
Load
Radius
(ft)
Boom
Angle
(deg.)
120 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
77.2
76.3
75.5
74.6
73.8
72.9
70.7
68.5
66.3
64.0
61.6
59.2
56.8
54.2
51.6
48.9
137,000
127,800
118,600
109,500
102,000
94,400
78,300
65,400
54,600
45,900
38,500
32,100
26,700
22,100
18,100
14,600
Load
Radius
(ft)
Boom
Angle
(deg.)
130 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
77.2
76.3
75.5
74.6
73.8
72.9
70.7
68.5
66.3
64.0
61.6
59.2
56.8
54.2
51.6
134,400
125,300
116,100
107,100
99,600
92,100
76,100
63,200
52,600
44,000
36,600
30,300
25,000
20,400
16,400
Load
Radius
(ft)
Boom
Angle
(deg.)
140 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
77.2
76.3
75.5
74.6
73.8
72.9
70.7
68.5
66.3
64.0
61.6
59.2
56.8
54.2
51.6
48.9
43.0
154,800
145,200
135,600
126,000
118,200
110,400
93,500
79,900
68,800
59,600
51,800
45,200
39,500
34,600
30,300
26,400
20,100
Load
Radius
(ft)
Boom
Angle
(deg.)
70 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
77.2
76.3
75.5
74.6
73.8
72.9
70.7
68.5
66.3
64.0
61.6
59.2
56.8
54.2
51.6
48.9
43.0
151,700
142,200
132,600
123,100
115,300
107,600
90,800
77,400
66,400
57,300
49,500
42,900
37,300
32,400
28,200
24,500
18,100
Load
Radius
(ft)
Boom
Angle
(deg.)
80 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
77.2
76.3
75.5
74.6
73.8
72.9
70.7
68.5
66.3
64.0
61.6
59.2
56.8
54.2
51.6
48.9
43.0
148,600
139,200
129,700
120,300
112,500
104,800
88,200
74,800
63,900
54,900
47,200
40,700
35,100
30,200
26,000
22,300
16,100
Load
Radius
(ft)
Boom
Angle
(deg.)
90 ft Jib
360
ﾟ
Rated Load
(lbs)
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
77.2
76.3
75.5
74.6
73.8
72.9
70.7
68.5
66.3
64.0
61.6
59.2
56.8
54.2
51.6
48.9
43.0
145,800
136,400
127,000
117,600
110,000
102,300
85,800
72,400
61,700
52,700
45,100
38,700
33,100
28,400
24,200
20,500
14,300
Load
Radius
(ft)
Boom
Angle
(deg.)
100 ft Jib
360
ﾟ
Rated Load
(lbs)
140' Boom
140' Boom
6
Reeves
6
Reeves
6
Reeves
6
Reeves
6
Reeves
6
Reeves
6
Reeves
6
Reeves
