106 / 180
Lu ng Boom/Jib - SPECIFICATIONS
104
Lu ng Boomwith Lu ng Lift Capacities
Full Counterweights (200,650 lbs) - Carbody weights (60,240 lbs)
Refer to notes on page 88- 89.
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
78.9
78.0
77.1
76.2
75.2
74.3
73.4
72.5
71.5
69.1
66.7
64.3
61.8
59.2
56.5
53.8
50.9
47.9
44.7
171,300 *
163,100 *
155,000 *
146,100
135,500
125,000
114,500
106,900
99,200
82,900
69,800
59,000
50,500
43,100
36,700
30,900
26,500
22,400
18,800
Load
Radius
(ft)
Boom
Angle
(deg.)
110 ft Jib
360
ﾟ
Rated Load
(lbs)
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
78.9
78.0
77.1
76.2
75.2
74.3
73.4
72.5
71.5
69.1
66.7
64.3
61.8
59.2
56.5
53.8
50.9
47.9
44.7
168,900 *
160,900 *
152,900 *
144,100
133,600
123,000
112,600
105,000
97,400
81,100
68,100
57,500
49,000
41,600
35,100
29,400
24,900
20,900
17,200
Load
Radius
(ft)
Boom
Angle
(deg.)
120 ft Jib
360
ﾟ
Rated Load
(lbs)
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
78.9
78.0
77.1
76.2
75.2
74.3
73.4
72.5
71.5
69.1
66.7
64.3
61.8
59.2
56.5
53.8
50.9
47.9
44.7
165,200 *
157,400 *
149,500 *
140,800
130,300
119,900
109,500
102,000
94,400
78,200
65,200
54,800
46,300
38,900
32,500
27,000
22,500
18,600
15,000
Load
Radius
(ft)
Boom
Angle
(deg.)
130 ft Jib
360
ﾟ
Rated Load
(lbs)
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
78.9
78.0
77.1
76.2
75.2
74.3
73.4
72.5
71.5
69.1
66.7
64.3
61.8
59.2
56.5
53.8
50.9
47.9
161,300 *
153,800 *
146,400 *
138,000
127,700
117,300
107,100
99,500
92,000
75,900
63,000
52,800
44,300
37,000
30,700
25,200
20,800
16,800
Load
Radius
(ft)
Boom
Angle
(deg.)
140 ft Jib
360
ﾟ
Rated Load
(lbs)
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
78.9
78.0
77.1
76.2
75.2
74.3
73.4
72.5
71.5
69.1
66.7
64.3
61.8
59.2
56.5
53.8
50.9
47.9
44.7
184,400 *
175,800 *
167,200 *
157,900
147,100
136,300
125,600
117,700
109,800
93,000
79,600
68,600
59,700
52,000
45,200
39,500
34,800
30,600
26,800
Load
Radius
(ft)
Boom
Angle
(deg.)
70 ft Jib
360
ﾟ
Rated Load
(lbs)
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
78.9
78.0
77.1
76.2
75.2
74.3
73.4
72.5
71.5
69.1
66.7
64.3
61.8
59.2
56.5
53.8
50.9
47.9
44.7
181,000 *
172,800 *
164,700 *
155,700
144,900
134,100
123,400
115,600
107,800
91,000
77,500
66,800
57,800
50,100
43,500
37,800
33,000
28,800
25,100
Load
Radius
(ft)
Boom
Angle
(deg.)
80 ft Jib
360
ﾟ
Rated Load
(lbs)
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
78.9
78.0
77.1
76.2
75.2
74.3
73.4
72.5
71.5
69.1
66.7
64.3
61.8
59.2
56.5
53.8
50.9
47.9
44.7
177,800 *
169,600 *
161,400 *
152,400
141,700
130,900
120,300
112,500
104,800
88,200
74,900
64,100
55,300
47,700
41,100
35,300
30,700
26,600
22,900
Load
Radius
(ft)
Boom
Angle
(deg.)
90 ft Jib
360
ﾟ
Rated Load
(lbs)
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
78.9
78.0
77.1
76.2
75.2
74.3
73.4
72.5
71.5
69.1
66.7
64.3
61.8
59.2
56.5
53.8
50.9
47.9
44.7
174,200 *
166,300 *
158,400 *
149,600
138,900
128,200
117,600
110,000
102,300
85,900
72,700
61,900
53,200
45,700
39,100
33,400
28,800
24,600
21,000
Load
Radius
(ft)
Boom
Angle
(deg.)
100 ft Jib
360
ﾟ
Rated Load
(lbs)
130' Boom
130' Boom
8
Reeves
8
Reeves
8
Reeves
8
Reeves
6
Reeves
6
Reeves
6
Reeves
6
Reeves
