Lu ng Boom/Jib - SPECIFICATIONS
101
Lu ng Boomwith Lu ng Lift Capacities
Full Counterweights (200,650 lbs) - Carbody weights (60,240 lbs)
Refer to notes on page 88- 89.
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
79.0
77.9
76.8
75.7
74.6
73.5
72.4
71.3
70.2
69.1
67.9
65.0
62.1
59.0
55.8
52.5
49.0
45.4
176,800 *
172,200 *
162,700
149,800
136,900
124,600
113,800
103,000
92,300
85,000
77,800
62,300
50,100
40,000
32,000
25,100
19,200
14,400
Load
Radius
(ft)
Boom
Angle
(deg.)
190 ft Jib
360
ﾟ
Rated Load
(lbs)
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
79.0
77.9
76.8
75.7
74.6
73.5
72.4
71.3
70.2
69.1
67.9
65.0
62.1
59.0
55.8
52.5
172,000 *
167,500 *
158,200
145,500
132,800
120,700
109,900
99,200
88,500
81,400
74,200
58,900
46,800
36,900
29,000
22,200
Load
Radius
(ft)
Boom
Angle
(deg.)
200 ft Jib
360
ﾟ
Rated Load
(lbs)
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
79.0
77.9
76.8
75.7
74.6
73.5
72.4
71.3
70.2
69.1
67.9
65.0
62.1
59.0
55.8
52.5
49.0
45.4
189,900 *
184,800 *
174,800
161,600
148,300
135,800
124,600
113,500
102,400
95,000
87,600
71,800
59,100
48,800
40,600
33,600
27,500
22,300
Load
Radius
(ft)
Boom
Angle
(deg.)
150 ft Jib
360
ﾟ
Rated Load
(lbs)
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
79.0
77.9
76.8
75.7
74.6
73.5
72.4
71.3
70.2
69.1
67.9
65.0
62.1
59.0
55.8
52.5
49.0
45.4
187,700 *
182,700 *
172,900
159,700
146,500
134,000
122,900
111,800
100,900
93,500
86,100
70,200
57,600
47,500
40,200
33,600
27,500
22,300
Load
Radius
(ft)
Boom
Angle
(deg.)
160 ft Jib
360
ﾟ
Rated Load
(lbs)
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
79.0
77.9
76.8
75.7
74.6
73.5
72.4
71.3
70.2
69.1
67.9
65.0
62.1
59.0
55.8
52.5
49.0
45.4
185,500 *
180,700 *
170,900
157,700
144,600
132,100
121,000
110,000
99,100
91,700
84,300
68,600
56,000
45,900
37,600
30,500
24,500
19,400
Load
Radius
(ft)
Boom
Angle
(deg.)
170 ft Jib
360
ﾟ
Rated Load
(lbs)
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
79.0
77.9
76.8
75.7
74.6
73.5
72.4
71.3
70.2
69.1
67.9
65.0
62.1
59.0
55.8
52.5
49.0
45.4
181,800 *
177,100 *
167,400
154,400
141,400
129,000
118,000
107,100
96,300
88,900
81,600
66,000
53,600
43,500
35,400
28,300
22,300
17,400
Load
Radius
(ft)
Boom
Angle
(deg.)
180 ft Jib
360
ﾟ
Rated Load
(lbs)
110' Boom
110' Boom
8
Reeves
8
Reeves
8
Reeves
8
Reeves
6
Reeves
6
Reeves
