Lu ng Boom/Jib - SPECIFICATIONS
96
Lu ng Boomwith Lu ng Lift Capacities
Full Counterweights (200,650 lbs) - Carbody weights (60,240 lbs)
Refer to notes on page 88- 89.
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
77.8
76.4
75.1
73.8
72.4
71.0
69.7
68.3
66.9
65.5
64.0
62.5
58.8
54.8
50.7
46.2
248,900 *
229,600 *
211,400 *
194,300
177,900
161,500
146,700
135,400
124,000
112,800
105,200
97,600
81,300
68,300
57,900
49,500
Load
Radius
(ft)
Boom
Angle
(deg.)
110 ft Jib
360
ﾟ
Rated Load
(lbs)
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
77.8
76.4
75.1
73.8
72.4
71.0
69.7
68.3
66.9
65.5
64.0
62.5
58.8
54.8
50.7
46.2
245,800 *
226,500 *
208,500 *
191,500
175,200
158,800
144,100
132,800
121,500
110,400
102,800
95,200
79,000
66,100
55,700
47,300
Load
Radius
(ft)
Boom
Angle
(deg.)
120 ft Jib
360
ﾟ
Rated Load
(lbs)
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
77.8
76.4
75.1
73.8
72.4
71.0
69.7
68.3
66.9
65.5
64.0
62.5
58.8
54.8
50.7
46.2
242,600 *
223,400 *
205,400 *
188,500
172,200
155,900
141,300
130,000
118,800
107,700
100,200
92,700
76,500
63,700
53,500
45,100
Load
Radius
(ft)
Boom
Angle
(deg.)
130 ft Jib
360
ﾟ
Rated Load
(lbs)
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
77.8
76.4
75.1
73.8
72.4
71.0
69.7
68.3
66.9
65.5
64.0
62.5
58.8
54.8
50.7
46.2
238,800 *
220,000 *
202,200 *
185,400
169,200
153,000
138,400
127,200
115,900
104,900
97,500
90,100
74,100
61,300
51,000
42,900
Load
Radius
(ft)
Boom
Angle
(deg.)
140 ft Jib
360
ﾟ
Rated Load
(lbs)
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
77.8
76.4
75.1
73.8
72.4
71.0
69.7
68.3
66.9
65.5
64.0
62.5
58.8
54.8
50.7
46.2
259,700 *
241,600 *
223,100 *
205,500
188,800
172,000
156,800
145,200
133,700
122,300
114,500
106,700
90,000
76,600
65,900
57,200
Load
Radius
(ft)
Boom
Angle
(deg.)
70 ft Jib
360
ﾟ
Rated Load
(lbs)
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
77.8
76.4
75.1
73.8
72.4
71.0
69.7
68.3
66.9
65.5
64.0
62.5
58.8
54.8
50.7
46.2
257,000 *
237,200 *
218,800 *
201,400
184,800
168,100
153,100
141,600
130,100
118,700
111,000
103,300
86,700
73,600
63,000
54,300
Load
Radius
(ft)
Boom
Angle
(deg.)
80 ft Jib
360
ﾟ
Rated Load
(lbs)
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
77.8
76.4
75.1
73.8
72.4
71.0
69.7
68.3
66.9
65.5
64.0
62.5
58.8
54.8
50.7
46.2
255,300 *
235,700 *
217,300 *
199,900
183,300
166,700
151,800
140,400
128,900
117,600
109,900
102,200
85,700
72,700
62,100
53,400
Load
Radius
(ft)
Boom
Angle
(deg.)
90 ft Jib
360
ﾟ
Rated Load
(lbs)
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
60.0
65.0
70.0
77.8
76.4
75.1
73.8
72.4
71.0
69.7
68.3
66.9
65.5
64.0
62.5
58.8
54.8
50.7
46.2
253,600 *
233,900 *
215,700 *
198,400
181,900
165,400
150,500
139,000
127,600
116,300
108,700
101,000
84,600
71,600
61,000
52,500
Load
Radius
(ft)
Boom
Angle
(deg.)
100 ft Jib
360
ﾟ
Rated Load
(lbs)
90' Boom
90' Boom
10
Reeves
10
Reeves
10
Reeves
10
Reeves
10
Reeves
10
Reeves
10
Reeves
10
Reeves
