Lu ng Boom/Jib - SPECIFICATIONS
92
Lu ng Boomwith Lu ng Lift Capacities
Full Counterweights (200,650 lbs) - Carbody weights (60,240 lbs)
Refer to notes on page 88- 89.
22.0
24.0
26.0
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
79.3
77.6
75.9
74.1
72.4
70.6
68.8
67.0
65.2
63.3
61.3
59.4
57.4
55.3
53.2
47.5
259,900 *
259,900 *
259,900 *
245,600 *
229,400 *
213,100 *
196,000
178,400
160,800
145,200
133,900
122,600
111,500
103,900
96,400
80,400
Load
Radius
(ft)
Boom
Angle
(deg.)
110 ft Jib
360
ﾟ
Rated Load
(lbs)
22.0
24.0
26.0
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
79.3
77.6
75.9
74.1
72.4
70.6
68.8
67.0
65.2
63.3
61.3
59.4
57.4
55.3
53.2
47.5
255,900 *
255,900 *
255,900 *
242,000 *
226,100 *
210,000 *
193,000
175,400
157,900
142,300
131,000
119,800
108,600
101,100
93,700
77,700
Load
Radius
(ft)
Boom
Angle
(deg.)
120 ft Jib
360
ﾟ
Rated Load
(lbs)
22.0
24.0
26.0
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
79.3
77.6
75.9
74.1
72.4
70.6
68.8
67.0
65.2
63.3
61.3
59.4
57.4
55.3
53.2
47.5
251,500 *
251,500 *
251,500 *
238,100 *
222,600 *
206,400 *
189,500
172,100
154,700
139,300
128,000
116,700
105,500
98,100
90,700
74,900
Load
Radius
(ft)
Boom
Angle
(deg.)
130 ft Jib
360
ﾟ
Rated Load
(lbs)
22.0
24.0
26.0
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
79.3
77.6
75.9
74.1
72.4
70.6
68.8
67.0
65.2
63.3
61.3
59.4
57.4
55.3
53.2
47.5
246,600 *
246,600 *
246,600 *
233,800 *
218,800 *
202,800 *
186,000
168,700
151,400
136,000
124,800
113,700
102,700
95,300
87,900
72,200
Load
Radius
(ft)
Boom
Angle
(deg.)
140 ft Jib
360
ﾟ
Rated Load
(lbs)
22.0
24.0
26.0
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
79.3
77.6
75.9
74.1
72.4
70.6
68.8
67.0
65.2
63.3
61.3
59.4
57.4
55.3
53.2
47.5
275,500 *
275,500 *
275,500 *
259,900 *
242,300 *
225,600 *
208,200
190,200
172,300
156,300
144,700
133,100
121,600
113,900
106,300
89,800
Load
Radius
(ft)
Boom
Angle
(deg.)
70 ft Jib
360
ﾟ
Rated Load
(lbs)
22.0
24.0
26.0
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
79.3
77.6
75.9
74.1
72.4
70.6
68.8
67.0
65.2
63.3
61.3
59.4
57.4
55.3
53.2
47.5
270,200 *
270,200 *
270,200 *
254,900 *
237,700 *
221,100 *
203,800
186,000
168,200
152,400
140,800
129,300
117,900
110,300
102,700
86,400
Load
Radius
(ft)
Boom
Angle
(deg.)
80 ft Jib
360
ﾟ
Rated Load
(lbs)
22.0
24.0
26.0
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
79.3
77.6
75.9
74.1
72.4
70.6
68.8
67.0
65.2
63.3
61.3
59.4
57.4
55.3
53.2
47.5
264,500 *
264,500 *
264,500 *
249,700 *
232,900 *
216,600 *
199,500
181,700
164,000
148,200
136,800
125,400
114,100
106,600
99,100
82,900
Load
Radius
(ft)
Boom
Angle
(deg.)
90 ft Jib
360
ﾟ
Rated Load
(lbs)
22.0
24.0
26.0
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
55.0
79.3
77.6
75.9
74.1
72.4
70.6
68.8
67.0
65.2
63.3
61.3
59.4
57.4
55.3
53.2
47.5
262,300 *
262,300 *
262,300 *
247,700 *
231,100 *
214,900 *
197,800
180,100
162,400
146,700
135,400
124,000
112,800
105,300
97,700
81,700
Load
Radius
(ft)
Boom
Angle
(deg.)
100 ft Jib
360
ﾟ
Rated Load
(lbs)
70' Boom
70' Boom
10
Reeves
10
Reeves
10
Reeves
10
Reeves
10
Reeves
10
Reeves
10
Reeves
10
Reeves
