STANDARDCONFIGURATION
CRANE - SUPPLEMENTAL DATA
Barge (0 degree thru 3 degree machine list)
14. Weight of recommended hook block.
Hook block
386
USt
220
USt
110
USt
50
USt
BALL
HOOK
Weight : lbs
14,110 9,040 5,950 4,850 1,985
If the weight of hook block to be used is lighter than the
recommended weight, the boom may turnover backward
or it is difficult to lower the empty hook block.
15. The rated load of work when the strut guy line for
luffing jib is installed on the boom surface is value in the
rated load chart minus the value in the table below.
Crane Boom
Boom length : ft
78
98
118
138
Reduced amount : lbs 2,600
2,400
2,400
2,400
Boom length : ft
157
177
197
217
Reduced amount : lbs 2,400
2,600
2,600
2,800
Boom length : ft
236
256
276
Reduced amount : lbs 2,800
3,000
2,600
16. Lifting capacities listed apply only to the machine as
originally manufactured and designed by KOBELCO
CONSTRUCTION MACHINERY CO.,LTD.
Modifications to this machine or use of equipment other
than that specified can reduce operating capacity.
Operation of this equipment in excess of rated loads or
disregard of instruction voids the warranty.
