STANDARDCONFIGURATION
CRANE - SUPPLEMENTAL DATA
Heavy Fixed Jib
16. The rated load of the work when the strut guy line is
installed on the boom upper surface is value in the rated
load chart minus the value in the table below.
Boom length : ft
98
118
138
157
Reduced amount : lbs 1,900
1,700
1,700
1,700
Boom length : ft
177
197
217
236
Reduced amount : lbs 1,700
1,700
1,900
2,200
17. Lifting capacities listed apply only to the machine as
originally manufactured and designed by KOBELCO
CONSTRUCTION MACHINERY CO.,LTD. Modifications
to this machine or use of equipment other than that
specified can reduce operating capacity.
18. Designed and rated to comply with ASME B30.5-2018.
Operation of this equipment in excess of rated loads or
disregard of instruction voids the warranty.
