STANDARDCONFIGURATION
LUFFINGBOOM / JIB - TRANSPORTATION PLAN
Configuration : Standard LF 197′ + 197′ (Counterweight : 308,600 lbs, Carbody weight 88,200 lbs)
Item
Qty.
Net wt.
Trailer
k-lbs m-ton #1 #2 #3 #4 #5 #6 #7 #8 #9 #10 #11 #12 #13 #14 #15 #16
Base machine without H1 and H2 hoist winch
1 91.6 41.5 1
H1 hoist non-free fall winch with 1,969′ wire rope 1 10.4 4.7
1
H2 hoist non-free fall winch with 1,969′ wire rope 1 10.4 4.7
1
Standard mast w/W1 winch
1 22.6 10.2
1
Left crawler frame with 52″ shoe
1 64.8 29.4
1
Right crawler frame with 52″ shoe
1 64.8 29.4
1
Base counterweight
1 44.1 20.0
1
Counterweight (20,050 lbs)
10 22.1 10.0
1 1 1 1 1 1
2 2
Counterweight (11,025 lbs)
4 11.0 5.0
1 1 1
1
Base carbody weight
2 38.7 17.6
1
1
Carbody weight w/step
2 6.1 2.8
1
1
Base boom w/W2 winch
1 27.9 12.7
1
20′ boom insert (**)
1 5.5 2.5
1
40′ boom insert (**)
3 9.6 4.4
1 1 1
Boom tip w/26′ taper boom (**)
1 18.1 8.2
1
Base jib w/Fr and Re strut
1 19.5 8.9
1
20′ jib insert w/guy lines
1 2.4 1.1
1
40′ jib insert w/guy lines
3 4.2 1.9
1 1 1
Jib tip w/Aux.sheave and guy lines
1 8.2 3.7
1
50 US ton hook block
1 4.9 2.2
1
15 US ton ball hook
1 2.0 0.9
1
(**) : including guy lines for crane and luffing strut. Gross wt. (×1,000 lbs) 91.6 43.4 64.8 64.8 44.1 27.9 46.6 46.9 46.9 46.9 46.3 46.4 43.3 44.8 44.1 44.1
Trailer #1
Trailer #9
Trailer #2
Trailer #10
Trailer #3
Trailer #11
Trailer #4
Trailer #12
Trailer #5
Trailer #13
Trailer #6
Trailer #14
Trailer #7
Trailer #15
Trailer #8
Trailer #16
