87 / 118
85
STANDARDCONFIGURATION
LUFFINGBOOM / JIB - SUPPLEMENTAL DATA
Luffing Jib
16. Maximum hoist load for number of reeving parts of line
for hoist rope.
Main Boom Hoist Loads (Single Drum)
No. of Parts of line
1
2
3
4
Max. Loads : lbs
33,000 66,100 99,200 132,200
Max. Loads : t
15.0
30.0
45.0
60.0
No. of Parts of line
5
6
7
8
Max. Loads : lbs 165,300 198,400 231,400 264,500
Max. Loads : t
75.0
90.0
105.0
120.0
No. of Parts of line
9
10
11
12
Max. Loads : lbs 297,600 330,600 363,700 396,800
Max. Loads : t
135.0
150.0
165.0
180.0
No. of Parts of line
13
14
Max. Loads : lbs 426,500 454,100
Max. Loads : t
193.5
206.0
Jib Hoist Loads (Double Drum)
No. of Parts of line 4 (2×2)
6 (2×3)
8 (2×4)
Max. Loads : lbs 132,200 198,400 264,500
Max. Loads : t
60.0
90.0
120.0
Jib Hoist Loads (Single Drum)
No. of Parts of line
1
2
3
4
Max. Loads : lbs
33,000 66,100 99,200 132,200
Max. Loads : t
15.0
30.0
45.0
60.0
No. of Parts of line
5
6
7
8
Max. Loads : lbs 165,300 198,400 231,400 264,500
Max. Loads : t
75.0
90.0
105.0
120.0
Auxiliary Hoist Loads
No. of Parts of line
1
2
Max. Loads : lbs
33,000 66,100
Max. Loads : t
15.0
30.0
17. Weight of recommended hook block.
Hook block
220
USt
110
USt
50
USt
BALL
HOOK
Weight : lbs
9,040
5,950
4,850
1,985
Number of sheave
7
3
1
-
If the weight of hook block to be used is lighter than the
recommended weight, the jib may turnover backward or
it is difficult to lower the empty hook block.
15. Maximum number of reeving parts of line for hoist rope.
(1) Luffing Jib (Double Drum)
Boom
Length
: ft
Jib Length : ft
78 98 118 138 157 177 197 217
98
8
8
8
6
6
4
4
4
118 8
8
8
6
6
4
4
4
138 8
8
8
6
6
4
4
4
157 8
8
8
6
6
4
4
4
177 8
8
8
6
6
4
4
4
197 8
8
6
6
4
4
4
4
(2) Luffing Jib (Single Drum)
Boom
Length
: ft
Jib Length : ft
78 98 118 138 157 177 197 217
98
8
8
7
6
5
4
3
3
118 8
7
7
6
5
4
3
3
138 7
7
6
6
5
4
3
3
157 7
6
5
5
5
4
3
3
177 6
5
5
5
4
4
3
3
197 5
5
5
4
4
4
3
3
(3) Auxiliary
Boom
Length
: ft
Jib Length : ft
78 98 118 138 157 177 197 217
98
2
2
2
2
2
2
2
2
118 2
2
2
2
2
2
2
2
138 2
2
2
2
2
2
2
2
157 2
2
2
2
2
2
2
2
177 2
2
2
2
2
2
2
2
197 2
2
2
2
2
2
2
2
(4) Main boom with luffing jib
Boom
Length
: ft
Jib Length : ft
78 98 118 138 157 177 197 217
98 14 13 12 12 11 10 10 9
118 12 12 11 11 10 9
9
8
138 10 9
9
8
8
7
7
6
157 9
9
8
8
7
7
6
5
177 7
7
6
6
5
5
4
4
197 6
6
6
5
5
4
4
3
