CK3300G-2
LUFFINGBOOM / JIB - LIFTINGCHART
Luffing Jib Lift Capacity
Counterweights : 308,600 lbs (140,000 kg) Carbody weights : 88,200 lbs (40,000 kg)
98 ft (30 m) Boom
157 ft (48 m) Jib
Load
Radius
(ft)
Boom Angle (deg.)
88
86
83
78
73
68
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
44.0
46.0
48.0
50.0
55.0
60.0 73.3 153,600 *
65.0 71.4 149,900 *
70.0 69.5 144,300 * 70.8 150,100 *
75.0 67.5 137,700 * 68.9 142,700 *
80.0 65.5 129,900 * 66.9 135,200 * 69.0 134,300
85.0 63.5 119,800 * 64.9 127,000
67.1 124,200
90.0 61.4 111,200 * 62.9 118,300
65.1 115,700
95.0 59.3 103,700 * 60.8 110,500
63.0 108,100
100.0 57.2
97,200 * 58.7 103,700
61.0 101,300
110.0 52.7
86,100 * 54.3
91,900
56.7
89,900
120.0 47.9
77,400 * 49.7
82,600
52.2
80,800
56.1
77,600
130.0 42.8
69,500 * 44.6
74,700
47.4
72,900
51.6
70,000
55.5
67,200
140.0 37.0
61,000 * 39.1
66,700
42.1
66,200
46.7
63,600
50.9
61,000
150.0 30.3
50,100 * 32.9
55,600 * 36.3
60,600
41.5
58,200
46.0
55,800
160.0 21.9
40,100 * 25.2
45,200 * 29.5
52,200 * 35.5
53,600
40.6
51,300
45.1
49,000
170.0
28.6
49,600
34.6
47,500
39.7
45,300
180.0
27.4
44,100
33.5
42,100
190.0
17.7
41,000
26.0
39,100
200.0
210.0
220.0
230.0
240.0
250.0
98 ft (30 m) Boom
177 ft (54 m) Jib
Load
Radius
(ft)
Boom Angle (deg.)
88
86
83
78
73
68
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
44.0
46.0
48.0
50.0
55.0
60.0
65.0 73.5 122,700 *
70.0 71.8 116,900 *
75.0 70.1 111,000 *
71.3 115,100 *
80.0 68.4 105,600 * 69.6 109,300 *
85.0 66.6 100,600 *
67.9 104,100 *
90.0 64.9
96,200 * 66.1
99,400 * 68.0 104,400 *
95.0 63.0
92,100 * 64.3
95,000 * 66.2
99,600 *
100.0 61.2
88,400 * 62.5
91,000 * 64.4
95,300 *
110.0 57.4
81,700 * 58.8
83,900 * 60.8
87,600 *
120.0 53.5
75,500 * 54.9
77,700 *
57.0
80,000
60.3
77,400
130.0 49.3
69,500 * 50.8
71,600 * 53.0
72,700
56.5
69,800
140.0 44.9
63,600 * 46.5
65,600 * 48.8
66,000
52.5
63,300
55.9
60,700
150.0 40.0
58,400 *
41.8
60,400 * 44.3
60,400
48.3
57,800
51.9
55,300
160.0 34.6
49,700 * 36.6
53,500 * 39.4
55,600
43.7
53,300
47.6
50,900
51.2
48,800
170.0 28.3
41,200 * 30.7
45,700 * 34.0
50,200
38.8
49,200
43.1
47,000
46.9
45,000
180.0
27.5
43,600
33.2
45,600
38.0
43,600
42.2
41,600
190.0
19.2
35,000 * 26.6
42,400
32.3
40,400
37.1
38,600
200.0
25.6
37,800
31.3
36,100
210.0
24.2
33,700
220.0
230.0
240.0
250.0
Ratings shown in
in the table require double-drum specifications.
Note : Designed and rated to comply with ASME Code B30.5
Capacities based on factors other than machine stability such as structural competence are shown by asterisk * in the charts.
Refer to notes on 84 to 86.
