CK3300G-2
LUFFINGBOOM / JIB - LIFTINGCHART
Luffing Jib Lift Capacity
Counterweights : 308,600 lbs (140,000 kg) Carbody weights : 88,200 lbs (40,000 kg)
118 ft (36 m) Boom
78 ft (24 m) Jib
Load
Radius
(ft)
Boom Angle (deg.)
88
86
83
78
73
68
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
44.0 68.7 260,200 b *
46.0 67.1 253,600 b * 70.5 253,600 b *
48.0 65.5 243,200 b * 68.9 243,200 b *
50.0 63.9 233,400 b * 67.3 233,400 b *
55.0 59.8 209,500 * 63.3 212,200 *
60.0 55.4 184,500 * 59.1 194,400 * 64.4 192,400 *
65.0 50.8 164,300 * 54.7 177,900 * 60.3 174,800
70.0 45.8 148,400 * 50.0 163,400
55.9 160,400
75.0 40.4 134,600 * 45.0 149,900
51.3 147,500
60.6 141,900
80.0 34.2 120,100 * 39.5 136,200 * 46.4 136,100
56.3 130,700
85.0 26.8
99,900 * 33.2 119,800 *
41.0 126,000
51.7 120,900
90.0
25.5
99,800 * 35.0 117,500
46.9 112,700
95.0
27.7 105,300
41.5 105,400
52.0 101,100
100.0
47.1
94,800
110.0
35.8
84,300
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
230.0
240.0
250.0
118 ft (36 m) Boom
98 ft (30 m) Jib
Load
Radius
(ft)
Boom Angle (deg.)
88
86
83
78
73
68
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
44.0 73.2 259,500 b *
46.0 71.9 252,700 b *
48.0 70.7 242,900 b *
50.0 69.4 233,400 b * 72.1 227,400 b *
55.0 66.3 212,200 * 69.0 212,200 *
60.0 63.0 188,600 * 65.8 194,200 *
65.0 59.7 167,900 * 62.5 177,100
66.7 173,700
70.0 56.2 151,500 * 59.2 162,500
63.4 159,300
75.0 52.6 137,700 * 55.7 149,700
60.1 146,400
80.0 48.8 126,000 * 52.0 138,500
56.6 135,000
63.7 129,400
85.0 44.7 116,100 * 48.2 128,200
53.0 124,900
60.4 119,800
90.0 40.4 107,700 * 44.1 118,900 * 49.3 116,400
57.0 111,600
95.0 35.5
99,300 * 39.7 110,100 * 45.2 108,800
53.4 104,300
100.0
34.7 100,300 * 40.9 102,200
49.6
97,900
57.1
93,500
110.0
22.1
75,300 * 30.7
91,000
41.3
87,000
49.8
83,100
120.0
31.2
78,200
41.5
74,700
130.0
31.5
67,500
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
230.0
240.0
250.0
Ratings shown in
in the table require double-drum specifications.
Note : Designed and rated to comply with ASME Code B30.5
Capacities based on factors other than machine stability such as structural competence are shown by asterisk * in the charts.
Refer to notes on 84 to 86.
