CK3300G-2
LUFFINGBOOM / JIB - LIFTINGCHART
Luffing Jib Lift Capacity
Counterweights : 308,600 lbs (140,000 kg) Carbody weights : 88,200 lbs (40,000 kg)
118 ft (36 m) Boom
157 ft (48 m) Jib
Load
Radius
(ft)
Boom Angle (deg.)
88
86
83
78
73
68
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
44.0
46.0
48.0
50.0
55.0
60.0 73.6 160,100 *
65.0 71.7 152,400 *
70.0 69.7 144,900 *
75.0 67.8 137,700 * 69.4 143,800 *
80.0 65.8 130,200 *
67.5 136,100 *
85.0 63.8 121,100 * 65.5 126,800
90.0 61.7 112,300 * 63.5 118,200
66.0 115,000
95.0 59.6 104,700 *
61.4 110,400
64.0 107,400
100.0 57.5
98,000 * 59.3 103,500
62.0 100,700
110.0 53.0
86,800 * 54.9
91,900
57.7
89,200
120.0 48.3
77,900 * 50.3
82,500
53.3
80,100
57.9
76,400
130.0 43.1
70,500 * 45.4
74,500
48.5
72,300
53.5
68,900
140.0 37.4
63,600 * 39.9
67,700
43.4
65,700
48.8
62,500
53.6
59,400
150.0 30.8
55,200 * 33.8
62,000
37.8
60,200
43.7
57,100
48.9
54,200
160.0 22.6
44,300 * 26.4
50,900 *
31.3
55,400
38.0
52,600
43.8
49,900
48.8
47,200
170.0
31.6
48,700
38.2
46,100
43.8
43,600
180.0
31.7
42,700
38.1
40,400
190.0
23.8
39,700
31.7
37,500
200.0
23.7
35,000
210.0
220.0
230.0
240.0
250.0
118 ft (36 m) Boom
177 ft (54 m) Jib
Load
Radius
(ft)
Boom Angle (deg.)
88
86
83
78
73
68
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
Jib Angle
(deg.)
Jib Capacity
(lbs)
44.0
46.0
48.0
50.0
55.0
60.0
65.0 73.8 123,900 *
70.0 72.1 117,600 *
75.0 70.4 111,600 *
71.8 116,600 *
80.0 68.6 106,000 * 70.1 110,600 *
85.0 66.9 101,000 * 68.4 105,200 *
90.0 65.1
96,600 * 66.6 100,500 *
95.0 63.3
92,400 * 64.8
96,000 *
67.1 101,700 *
100.0 61.5
88,600 * 63.0
91,800 * 65.3
97,100 *
110.0 57.7
81,900 * 59.3
84,600 *
61.7
88,400
120.0 53.8
75,700 * 55.4
78,400 *
57.9
79,600
61.8
75,700
130.0 49.6
69,700 *
51.4
72,300 * 54.0
71,900
58.1
68,200
140.0 45.2
63,800 *
47.1
66,200 * 49.9
65,300
54.2
61,800
58.2
58,800
150.0 40.4
58,600 * 42.5
60,800 * 45.4
59,600
50.0
56,400
54.3
53,600
160.0 35.0
53,100 *
37.4
56,100 * 40.7
54,900
45.6
52,000
50.1
49,300
170.0 28.8
45,600 *
31.6
49,700 * 35.3
50,700
40.9
48,000
45.7
45,400
50.1
42,800
180.0
29.2
46,200
35.6
44,500
41.0
41,900
45.7
39,500
190.0
21.5
40,500 * 29.5
41,300
35.7
38,800
41.0
36,600
200.0
21.9
38,600
29.6
36,300
35.7
34,100
210.0
22.1
34,000
29.6
31,900
220.0
230.0
240.0
250.0
Ratings shown in
in the table require double-drum specifications.
Note : Designed and rated to comply with ASME Code B30.5
Capacities based on factors other than machine stability such as structural competence are shown by asterisk * in the charts.
Refer to notes on 84 to 86.
