STANDARDCONFIGURATION
CRANE - LIFTINGCHART
Fixed Jib Lift
Capacity
(without main hook weight deduct)
Counterweights : 220,500 lbs (100,000 kg) Carbody weights : 88,200 lbs (40,000 kg)
138 ft (42 m) Boom
40 ft jib
60 ft jib
80 ft jib
100 ft jib
Offset Angle (deg.)
Offset Angle (deg.)
Offset Angle (deg.)
Offset Angle (deg.)
10
30
10
30
10
30
10
30
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
42.4 80.0 58,400 *
49.6 80.0 46,700 *
56.1 80.0 26,600 *
60.1 80.0 14,900 *
45.0 79.1 57,700 *
55.0 78.4 45,400 *
60.0 78.7 26,300 *
65.0 78.5 14,800 *
50.0 77.5 56,400 * 54.2 80.0 42,300 * 60.0 76.9 44,000 *
65.0 77.3 25,500 *
70.0 77.3 14,400 *
55.0 75.8 54,900 * 55.0 79.7 42,200 * 65.0 75.4 42,700 * 68.0 80.0 29,700 * 70.0 75.9 24,800 *
75.0 76.1 13,800 *
60.0 74.2 53,500 * 60.0 78.0 41,800 * 70.0 73.9 41,400 * 70.0 79.0 29,700 * 75.0 74.6 24,100 * 79.6 80.0 17,800 * 80.0 74.8 13,400 *
65.0 72.6 52,100 * 65.0 76.4 41,100 * 75.0 72.4 40,300 * 75.0 77.5 29,500 * 80.0 73.3 23,500 * 80.0 79.6 17,700 * 85.0 73.5 13,000 * 89.8 80.0
9,700 *
70.0 70.9 50,800 * 70.0 74.6 40,100 * 80.0 70.9 39,100 * 80.0 75.9 29,200 * 85.0 71.8 23,000 * 85.0 78.1 17,600 * 90.0 72.3 12,600 * 90.0 79.6
9,600 *
75.0 69.2 49,600 * 75.0 72.9 38,900 * 85.0 69.3 38,100 * 85.0 74.3 28,900 * 90.0 70.5 22,500 * 90.0 76.7 17,300 * 95.0 71.0 12,100 * 95.0 78.3
9,600 *
80.0 67.4 48,600 * 80.0 71.1 37,600 * 90.0 67.7 37,200 * 90.0 72.7 28,500 * 95.0 69.0 21,900 * 95.0 75.2 16,900 * 100.0 69.7 11,700 * 100.0 77.0
9,400 *
85.0 65.7 47,600 * 85.0 69.4 36,400 * 95.0 66.1 36,300 * 95.0 71.1 27,700 * 100.0 67.6 21,300 * 100.0 73.8 16,600 * 110.0 67.2 11,100 * 110.0 74.4
9,000 *
90.0 63.9 46,300 * 90.0 67.5 35,400 * 100.0 64.5 35,500 * 100.0 69.5 26,900 * 110.0 64.7 20,300 * 110.0 70.8 15,900 * 120.0 64.4 10,600 * 120.0 71.6
8,700 *
95.0 62.1 45,000 * 95.0 65.7 34,400 * 110.0 61.3 33,500 * 110.0 66.1 25,400 * 120.0 61.8 19,200 * 120.0 67.7 15,500 * 130.0 61.7 10,100 * 130.0 68.8
8,400 *
100.0 60.3 43,900 * 100.0 63.8 33,500 * 120.0 57.9 31,000 * 120.0 62.6 24,100 * 130.0 58.6 18,400 * 130.0 64.5 15,000 * 140.0 58.9
9,600 * 140.0 65.9
8,000 *
110.0 56.5 41,800 110.0 59.9 31,800 * 130.0 54.4 28,800 * 130.0 58.9 23,000 * 140.0 55.4 17,700 * 140.0 61.2 14,600 * 150.0 56.0
9,200 * 150.0 62.8
7,900 *
120.0 52.5 39,600 120.0 55.8 30,500 * 140.0 50.6 26,800 * 140.0 55.0 22,000 * 150.0 52.2 17,000 * 150.0 57.8 14,100 * 160.0 52.9
8,700 * 160.0 59.7
7,700 *
130.0 48.3 37,300 130.0 51.5 29,400 * 150.0 46.6 25,300 * 150.0 50.9 21,200 * 160.0 48.6 16,300 * 160.0 54.1 14,000 * 170.0 49.7
8,300 * 170.0 56.4
7,500 *
140.0 43.8 34,200 140.0 46.8 28,500 * 160.0 42.4 24,000 * 160.0 46.4 20,500 * 170.0 44.9 15,800 * 170.0 50.1 13,600 * 180.0 46.5
8,200 * 180.0 52.9
7,200 *
150.0 38.8 31,300 150.0 41.6 27,800 * 170.0 37.7 22,600 * 170.0 41.5 20,000 * 180.0 40.8 15,300 * 180.0 45.8 13,400 * 190.0 42.9
7,900 * 190.0 49.2
7,200 *
160.0 33.2 28,300 160.0 35.7 27,300 180.0 32.4 21,500 * 180.0 35.6 19,700 * 190.0 36.4 15,000 * 190.0 41.1 13,400 * 200.0 39.0
7,700 * 200.0 45.0
7,000 *
165.9 30.0 26,600 168.2 30.0 26,400 184.1 30.0 21,100 * 189.2 30.0 19,600 * 200.0 31.3 14,500 * 200.0 35.4 13,400 * 210.0 34.8
7,400 * 210.0 40.4
7,000
203.4 30.0 14,500 * 208.3 30.0 13,400 * 220.0 30.0
6,800 * 220.0 35.1
6,400
228.9 30.0
5,900
Reeves
2
Reeves
2
Reeves
2
Reeves
1
Reeves
1
Reeves
1
Reeves
1
Reeves
1
157 ft (48 m) Boom
40 ft jib
60 ft jib
80 ft jib
100 ft jib
Offset Angle (deg.)
Offset Angle (deg.)
Offset Angle (deg.)
Offset Angle (deg.)
10
30
10
30
10
30
10
30
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
45.8 80.0 58,400 *
53.0 80.0 46,700 *
59.6 80.0 26,600 *
63.5 80.0 14,700 *
50.0 78.8 57,600 *
55.0 79.4 46,500 *
60.0 79.6 26,500 *
65.0 79.4 14,600 *
55.0 77.3 56,100 * 57.6 80.0 42,300 * 60.0 78.1 45,100 *
65.0 78.4 26,100 *
70.0 78.2 14,500 *
60.0 75.8 54,800 * 60.0 79.3 42,200 * 65.0 76.7 43,700 *
70.0 77.2 25,500 *
75.0 77.1 14,100 *
65.0 74.3 53,500 * 65.0 77.7 41,600 * 70.0 75.4 42,500 * 71.5 80.0 29,700 * 75.0 75.9 24,800 *
80.0 76.0 13,700 *
70.0 72.8 52,100 * 70.0 76.2 40,900 * 75.0 74.1 41,500 * 75.0 78.7 29,700 * 80.0 74.6 24,200 * 83.0 80.0 17,800 * 85.0 74.8 13,300 *
75.0 71.3 50,600 * 75.0 74.7 40,100 * 80.0 72.7 40,400 * 80.0 77.3 29,600 * 85.0 73.4 23,700 * 85.0 79.2 17,700 * 90.0 73.7 12,900 * 93.2 80.0
9,200 *
80.0 69.8 49,200 * 80.0 73.1 38,900 * 85.0 71.2 39,400 * 85.0 75.9 29,300 * 90.0 72.1 23,100 * 90.0 77.9 17,500 * 95.0 72.5 12,500 * 95.0 79.3
9,200 *
85.0 68.2 47,900 * 85.0 71.5 37,700 * 90.0 69.9 38,500 * 90.0 74.5 28,900 * 95.0 70.8 22,600 * 95.0 76.6 17,200 * 100.0 71.4 12,200 * 100.0 78.1
9,200 *
90.0 66.6 46,700 * 90.0 69.9 36,600 * 95.0 68.4 37,700 * 95.0 73.0 28,400 * 100.0 69.5 22,100 * 100.0 75.2 16,800 * 110.0 69.0 11,500 * 110.0 75.6
9,000 *
95.0 65.0 45,600 * 95.0 68.3 35,700 * 100.0 67.0 36,800 * 100.0 71.6 27,800 * 110.0 67.0 21,000 * 110.0 72.6 16,300 * 120.0 66.6 10,900 * 120.0 73.2
8,700 *
100.0 63.4 44,500 100.0 66.7 34,800 * 110.0 64.1 35,100 * 110.0 68.5 26,300 * 120.0 64.3 20,000 * 120.0 69.8 15,800 * 130.0 64.1 10,400 * 130.0 70.7
8,400 *
110.0 60.2 42,500 110.0 63.4 33,200 * 120.0 61.2 33,300 * 120.0 65.5 25,000 * 130.0 61.6 19,200 * 130.0 67.0 15,200 * 140.0 61.6 10,000 * 140.0 68.0
8,300 *
120.0 56.8 40,400 120.0 59.9 31,800 * 130.0 58.0 31,000 * 130.0 62.3 23,900 * 140.0 58.7 18,500 * 140.0 64.1 14,900 * 150.0 59.0
9,500 * 150.0 65.3
7,900 *
130.0 53.2 37,400 130.0 56.2 30,500 * 140.0 54.8 29,000 * 140.0 59.0 22,900 * 150.0 55.8 17,600 * 150.0 61.0 14,500 * 160.0 56.3
9,100 * 160.0 62.6
7,800 *
140.0 49.5 33,500 140.0 52.4 29,500 * 150.0 51.5 27,300 * 150.0 55.5 22,100 * 160.0 52.8 17,100 * 160.0 57.9 14,200 * 170.0 53.5
8,800 * 170.0 59.7
7,500 *
150.0 45.5 29,900 150.0 48.3 28,700 160.0 47.9 25,700 * 160.0 51.8 21,400 * 170.0 49.6 16,500 * 170.0 54.6 13,900 * 180.0 50.6
8,500 * 180.0 56.7
7,400 *
160.0 41.2 26,900 160.0 43.9 27,400 170.0 44.2 24,300 170.0 47.9 20,700 * 180.0 46.3 15,900 * 180.0 51.1 13,600 * 190.0 47.5
8,100 * 190.0 53.5
7,200 *
170.0 36.5 24,400 170.0 39.0 24,900 180.0 40.1 22,900 180.0 43.6 20,100 * 190.0 42.7 15,400 * 190.0 47.4 13,400 * 200.0 44.3
8,000 * 200.0 50.1
7,200 *
180.0 31.2 22,200 180.0 33.3 22,400 190.0 35.7 20,900 190.0 38.9 19,800 * 200.0 38.8 15,100 * 200.0 43.2 13,400 * 210.0 40.9
7,900 * 210.0 46.5
7,000 *
182.2 30.0 21,600 185.2 30.0 21,300 200.0 30.5 19,100 200.0 33.2 19,300 * 210.0 34.5 14,700 * 210.0 38.6 13,400 * 220.0 37.2
7,500 * 220.0 42.6
6,900 *
201.2 30.0 18,900 206.2 30.0 18,700 * 220.0 30.2 14,300 * 220.0 33.2 13,400 * 230.0 33.2
7,400 * 230.0 38.2
6,600
220.4 30.0 14,300 * 226.2 30.0 13,400 * 238.1 30.0
6,800 * 240.0 32.9
6,200
246.0 30.0
5,900
Reeves
2
Reeves
2
Reeves
2
Reeves
1
Reeves
1
Reeves
1
Reeves
1
Reeves
1
In case of 40 ft (12.2 m) jib length with offset angle 10 degrees and one part of line on hook, additional parts required-contract KOBELCO CONSTRUCTION MACHINERY U.S.A. INC.
Note : Designed and rated to comply with ASME Code B30.5
Capacities based on factors other than machine stability such as structural competence are shown by asterisk * in the charts.
Refer to notes on 27 to 29.
