STANDARDCONFIGURATION
CRANE - LIFTINGCHART
Fixed Jib Lift
Capacity
(without main hook weight deduct)
Counterweights : 220,500 lbs (100,000 kg) Carbody weights : 88,200 lbs (40,000 kg)
217 ft (66 m) Boom
40 ft jib
60 ft jib
80 ft jib
100 ft jib
Offset Angle (deg.)
Offset Angle (deg.)
Offset Angle (deg.)
Offset Angle (deg.)
10
30
10
30
10
30
10
30
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
56.1 80.0 58,200 *
63.3 80.0 46,500 *
69.8 80.0 26,600 *
73.7 80.0 14,700 *
60.0 79.0 57,700 *
65.0 79.6 46,400 *
70.0 79.7 26,500 *
75.0 79.5 14,600 *
65.0 78.0 56,400 * 67.9 80.0 42,100 * 70.0 78.5 45,200 *
75.0 78.8 26,200 *
80.0 78.6 14,500 *
70.0 76.8 55,400 * 70.0 79.4 42,000 * 75.0 77.4 44,200 *
80.0 77.8 25,700 *
85.0 77.7 14,100 *
75.0 75.7 54,400 * 75.0 78.3 41,600 * 80.0 76.4 43,300 * 81.7 80.0 29,700 * 85.0 76.8 25,000 *
90.0 76.8 13,700 *
80.0 74.5 53,400 * 80.0 77.2 41,100 * 85.0 75.3 42,400 * 85.0 79.0 29,700 * 90.0 75.8 24,500 * 93.3 80.0 17,800 * 95.0 75.9 13,400 *
85.0 73.3 52,600 * 85.0 76.0 40,500 * 90.0 74.2 41,400 * 90.0 77.9 29,700 * 95.0 74.8 24,100 * 95.0 79.4 17,700 * 100.0 74.9 13,100 * 103.5 80.0
9,200 *
90.0 72.2 51,400 * 90.0 74.8 39,800 * 95.0 73.2 40,600 * 95.0 76.8 29,500 * 100.0 73.8 23,600 * 100.0 78.4 17,500 * 110.0 73.0 12,600 * 110.0 78.5
9,200 *
95.0 71.0 50,200 95.0 73.6 39,000 * 100.0 72.1 39,800 * 100.0 75.7 29,100 * 110.0 71.8 22,800 * 110.0 76.3 17,000 * 120.0 71.1 12,000 * 120.0 76.6
9,100 *
100.0 69.9 48,900 100.0 72.4 38,100 * 110.0 69.9 38,400 * 110.0 73.5 28,400 * 120.0 69.7 21,900 * 120.0 74.2 16,400 * 130.0 69.2 11,500 * 130.0 74.6
8,800 *
110.0 67.4 44,200 110.0 70.0 36,400 * 120.0 67.7 37,000 * 120.0 71.2 27,300 * 130.0 67.6 21,000 * 130.0 72.1 16,100 * 140.0 67.2 11,000 * 140.0 72.6
8,500 *
120.0 65.1 38,500 120.0 67.5 35,000 * 130.0 65.4 34,600 * 130.0 68.9 26,300 * 140.0 65.5 20,300 * 140.0 69.9 15,700 * 150.0 65.2 10,600 * 150.0 70.5
8,400 *
130.0 62.6 33,700 130.0 65.0 33,600 140.0 63.1 30,900 140.0 66.5 25,300 * 150.0 63.3 19,600 * 150.0 67.7 15,400 * 160.0 63.2 10,200 * 160.0 68.4
8,100 *
140.0 60.0 29,700 140.0 62.4 30,800 150.0 60.8 27,300 150.0 64.2 24,300 * 160.0 61.1 19,000 * 160.0 65.4 15,100 * 170.0 61.2
9,700 * 170.0 66.3
7,900 *
150.0 57.4 26,200 150.0 59.8 27,200 160.0 58.3 24,200 160.0 61.6 23,600 * 170.0 58.9 18,300 * 170.0 63.1 14,700 * 180.0 59.0
9,400 * 180.0 64.1
7,800 *
160.0 54.7 23,200 160.0 57.0 24,100 170.0 55.8 21,500 170.0 59.1 22,900 * 180.0 56.6 17,800 * 180.0 60.7 14,400 * 190.0 56.9
9,200 * 190.0 61.9
7,700 *
170.0 51.9 20,600 170.0 54.1 21,300 180.0 53.3 19,200 180.0 56.4 20,900 * 190.0 54.1 17,400 * 190.0 58.2 14,100 * 200.0 54.6
8,900 * 200.0 59.6
7,400 *
180.0 49.0 18,300 180.0 51.2 19,000 190.0 50.6 17,200 190.0 53.6 18,500 200.0 51.7 16,500 * 200.0 55.7 14,000 * 210.0 52.3
8,500 * 210.0 57.2
7,400 *
190.0 45.9 16,200 190.0 48.0 16,700 200.0 47.8 15,300 200.0 50.8 16,600 210.0 49.1 14,900 210.0 53.0 13,600 * 220.0 50.0
8,300 * 220.0 54.8
7,200 *
200.0 42.7 14,300 200.0 44.7 14,900 210.0 44.9 13,600 210.0 47.7 14,800 220.0 46.5 13,300 220.0 50.2 13,500 * 230.0 47.6
8,100 * 230.0 52.3
7,200 *
210.0 39.3 12,900 210.0 41.2 13,100 220.0 41.8 12,300 220.0 44.5 13,300 230.0 43.7 11,900 230.0 47.3 12,800 240.0 45.0
8,000 * 240.0 49.5
7,000 *
220.0 35.6 11,300 220.0 37.3 11,600 230.0 38.5 10,800 230.0 41.1 11,700 240.0 40.7 10,600 240.0 44.1 11,600 250.0 42.3
7,700 * 250.0 46.8
7,000 *
230.0 31.5 10,000 230.0 33.0 10,200 240.0 34.9
9,600 240.0 37.3 10,400 250.0 37.5
9,500 250.0 40.8 10,100 260.0 39.4
7,400 * 260.0 43.7
7,000 *
233.4 30.0
9,700 236.4 30.0
9,400 250.0 31.0
8,400 250.0 33.0
9,000 260.0 34.0
8,500 260.0 37.1
8,900 270.0 36.3
7,300 * 270.0 40.4
7,000
252.3 30.0
8,300 257.3 30.0
8,300 270.0 30.2
7,400 270.0 32.9
7,900 280.0 33.0
6,800 * 280.0 36.8
6,600
271.6 30.0
7,200 277.3 30.0
7,200 289.2 30.0
6,300 * 290.0 32.8
6,200
297.1 30.0
5,900
Reeves
2
Reeves
2
Reeves
2
Reeves
1
Reeves
1
Reeves
1
Reeves
1
Reeves
1
236 ft (72 m) Boom
40 ft jib
60 ft jib
80 ft jib
100 ft jib
Offset Angle (deg.)
Offset Angle (deg.)
Offset Angle (deg.)
Offset Angle (deg.)
10
30
10
30
10
30
10
30
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
59.5 80.0 58,200 *
66.7 80.0 46,500 *
73.2 80.0 26,600 *
77.2 80.0 14,700 *
60.0 79.8 58,100 *
70.0 79.3 46,100 *
75.0 79.4 26,500 *
80.0 79.3 14,500 *
65.0 78.8 57,400 *
75.0 78.3 44,900 *
80.0 78.5 25,900 *
85.0 78.4 14,300 *
70.0 77.7 56,300 * 71.3 80.0 42,100 * 80.0 77.3 43,900 *
85.0 77.6 25,300 *
90.0 77.6 14,000 *
75.0 76.7 55,300 * 75.0 79.1 41,900 * 85.0 76.3 43,100 * 85.1 80.0 29,700 * 90.0 76.7 24,800 *
95.0 76.7 13,700 *
80.0 75.7 54,300 * 80.0 78.1 41,300 * 90.0 75.3 42,300 * 90.0 78.8 29,700 * 95.0 75.8 24,400 * 96.7 80.0 17,800 * 100.0 75.8 13,500 * 106.9 80.0
9,400 *
85.0 74.6 53,500 * 85.0 77.0 41,000 * 95.0 74.3 41,400 * 95.0 77.8 29,600 * 100.0 74.8 24,000 * 100.0 79.1 17,600 * 110.0 74.0 12,800 * 110.0 79.2
9,300 *
90.0 73.5 52,500 * 90.0 75.9 40,500 * 100.0 73.3 40,600 * 100.0 76.7 29,400 * 110.0 72.9 23,200 * 110.0 77.2 17,200 * 120.0 72.3 12,200 * 120.0 77.4
9,100 *
95.0 72.4 51,100 95.0 74.8 39,900 * 110.0 71.4 39,200 * 110.0 74.7 28,700 * 120.0 71.0 22,300 * 120.0 75.3 16,600 * 130.0 70.5 11,700 * 130.0 75.6
9,000 *
100.0 71.3 48,900 100.0 73.7 39,000 * 120.0 69.2 37,500 * 120.0 72.5 28,000 * 130.0 69.1 21,600 * 130.0 73.3 16,300 * 140.0 68.6 11,300 * 140.0 73.7
8,700 *
110.0 69.1 42,700 110.0 71.5 37,300 * 130.0 67.2 33,700 130.0 70.4 27,000 * 140.0 67.1 21,000 * 140.0 71.3 16,000 * 150.0 66.8 10,800 * 150.0 71.8
8,400 *
120.0 66.9 37,300 120.0 69.2 35,900 140.0 65.1 29,600 140.0 68.3 26,000 * 150.0 65.1 20,300 * 150.0 69.2 15,600 * 160.0 64.9 10,400 * 160.0 69.9
8,200 *
130.0 64.6 32,500 130.0 66.9 33,600 150.0 62.9 26,200 150.0 66.1 25,000 * 160.0 63.1 19,600 * 160.0 67.2 15,300 * 170.0 63.0 10,100 * 170.0 67.9
8,100 *
140.0 62.3 28,500 140.0 64.6 29,900 160.0 60.7 23,100 160.0 63.8 24,300 * 170.0 61.0 19,000 * 170.0 65.0 15,000 * 180.0 61.1
9,800 * 180.0 65.9
7,900 *
150.0 60.0 25,000 150.0 62.2 26,200 170.0 58.4 20,400 170.0 61.5 22,400 * 180.0 58.9 18,400 * 180.0 62.8 14,600 * 190.0 59.0
9,400 * 190.0 63.8
7,700 *
160.0 57.5 22,000 160.0 59.7 23,100 180.0 56.1 18,000 180.0 59.1 19,800 190.0 56.7 17,200 * 190.0 60.6 14,300 * 200.0 57.0
9,100 * 200.0 61.8
7,600 *
170.0 55.0 19,500 170.0 57.2 20,400 190.0 53.7 16,100 190.0 56.6 17,500 200.0 54.5 15,500 * 200.0 58.3 14,200 * 210.0 54.9
8,700 * 210.0 59.6
7,400 *
180.0 52.5 17,000 180.0 54.6 18,000 200.0 51.2 14,200 200.0 54.1 15,700 210.0 52.2 13,800 210.0 55.9 13,800 * 220.0 52.8
8,700 * 220.0 57.4
7,300 *
190.0 49.8 15,100 190.0 51.8 15,800 210.0 48.6 12,500 210.0 51.4 13,800 220.0 49.8 12,300 220.0 53.5 13,300 230.0 50.6
8,300 * 230.0 55.1
7,200 *
200.0 47.0 13,200 200.0 49.0 14,000 220.0 46.0 12,400 220.0 48.7 13,700 230.0 47.4 10,800 230.0 51.0 11,900 240.0 48.3
8,200 * 240.0 52.7
7,200 *
210.0 44.1 11,500 210.0 45.9 12,200 230.0 43.2 10,700 230.0 45.7 12,000 240.0 44.8
9,600 240.0 48.2 10,600 250.0 45.9
7,800 * 250.0 50.3
7,000 *
220.0 41.0 10,200 220.0 42.8 10,600 240.0 40.2
8,900 240.0 42.6 10,000 250.0 42.1
8,400 250.0 45.4
9,200 260.0 43.4
7,500 * 260.0 47.6
7,000 *
230.0 37.7
8,700 230.0 39.4
9,100 250.0 37.0
7,100 250.0 39.3
8,000 260.0 39.2
7,400 260.0 42.4
8,000 270.0 40.8
7,000 270.0 44.9
7,000
240.0 34.1
6,900 240.0 35.7
7,600
260.0 35.6
6,300 269.0 36.5
6,500 270.0 39.1
7,000 280.0 38.0
6,000 279.6 42.4
6,500
279.0 36.3
6,100
Reeves
2
Reeves
2
Reeves
2
Reeves
1
Reeves
1
Reeves
1
Reeves
1
Reeves
1
In case of 40 ft (12.2 m) jib length with offset angle 10 degrees and one part of line on hook, additional parts required-contract KOBELCO CONSTRUCTION MACHINERY U.S.A. INC.
Note : Designed and rated to comply with ASME Code B30.5
Capacities based on factors other than machine stability such as structural competence are shown by asterisk * in the charts.
Refer to notes on 27 to 29.
