SPECIFICATIONS
76
Barge
14 Counterweights (200,650 lbs) - 4 Carbody weights (60,240 lbs)
Refer to notes on page 72.
230' Boom
360° Rated Load (lbs)
130,900 *
130,700 *
125,200 *
119,700 *
108,100
98,900
90,500
83,400
76,700
70,300
64,200
59,100
54,600
50,600
43,700
38,000
33,300
29,300
26,000
23,100
20,600
18,200
16,100
14,200
45.9
46.0
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
0 Degree
Machine
List
Boom
Angle
(deg.)
Load
Radius
(ft)
80.0
79.9
79.5
79.0
77.7
76.4
75.1
73.8
72.5
71.2
69.9
68.6
67.2
65.8
63.1
60.2
57.3
54.3
51.1
47.8
44.4
40.6
36.6
32.2
Reeves
5
3
2
2
75,200 *
70,600 *
64,900
59,600
54,900
50,800
47,200
40,900
35,700
31,300
27,600
24,500
21,800
19,600
17,400
15,300
13,500
1 Degree
Machine
List
47,900 *
46,900 *
45,700 *
44,400 *
42,900 *
38,700
33,900
30,100
26,700
23,700
21,100
18,900
16,700
14,900
13,200
2 Degree
Machine
List
33,900 *
33,300 *
32,800 *
31,700 *
29,800 *
28,000 *
25,700
22,900
20,500
18,200
16,300
14,500
12,900
3 Degree
Machine
List
240' Boom
360° Rated Load (lbs)
120,100 *
119,400 *
116,400 *
107,400
97,300
88,900
81,700
75,300
69,500
64,000
58,900
54,300
50,200
43,300
37,600
32,900
29,000
25,600
22,900
20,200
17,800
15,700
13,800
12,100
47.5
48.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
0 Degree
Machine
List
Boom
Angle
(deg.)
Load
Radius
(ft)
80.0
79.9
79.4
78.2
77.0
75.8
74.5
73.3
72.0
70.8
69.5
68.2
66.9
64.3
61.6
58.8
56.0
53.0
50.0
46.8
43.4
39.8
35.8
31.5
Reeves
5
3
2
2
73,100 *
70,500 *
67,900 *
63,400
58,200
53,700
50,300
46,700
40,400
35,300
31,000
27,400
24,100
21,400
19,000
16,900
14,900
13,100
11,500
1 Degree
Machine
List
44,800 *
43,800 *
42,700 *
41,500 *
40,200 *
37,500 *
33,500
29,400
26,200
23,200
20,700
18,200
16,300
14,300
12,700
11,200
2 Degree
Machine
List
31,700 *
31,100 *
30,600 *
30,100 *
28,500 *
26,700 *
24,900 *
23,100 *
21,100
18,700
16,700
14,700
13,100
11,600
10,400
3 Degree
Machine
List
250' Boom
360° Rated Load (lbs)
108,200 *
108,000 *
103,100 *
95,800
87,400
80,300
74,000
68,300
63,300
58,600
54,100
49,900
43,000
37,400
32,700
28,700
25,400
22,400
19,700
17,400
15,200
13,300
11,600
10,100
49.5
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
0 Degree
Machine
List
Boom
Angle
(deg.)
Load
Radius
(ft)
80.0
79.9
78.7
77.5
76.3
75.2
74.0
72.8
71.6
70.3
69.1
67.9
65.4
62.8
60.2
57.5
54.8
51.9
48.9
45.8
42.5
38.9
35.1
30.8
Reeves
4
3
2
2
65,200 *
62,800 *
60,100 *
57,700 *
53,500
49,300
45,800
39,600
35,000
30,800
27,000
23,800
21,200
18,500
16,300
14,400
12,600
10,900
9,500
1 Degree
Machine
List
40,300 *
39,000 *
37,700 *
36,500 *
33,900 *
31,700 *
29,000 *
25,700
22,700
20,400
17,800
15,600
13,800
12,100
10,400
9,200
2 Degree
Machine
List
28,200 *
27,700 *
26,400 *
24,700 *
23,000 *
21,300 *
19,600 *
18,100 *
16,500 *
14,900
13,200
11,700
10,100
8,900
3 Degree
Machine
List
260' Boom
360° Rated Load (lbs)
98,500 *
97,000 *
93,700
85,600
78,700
72,500
66,800
62,000
57,600
53,400
49,500
42,600
36,900
32,200
28,200
24,900
22,000
19,300
16,700
14,600
12,600
11,000
9,400
8,000
51.1
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
230.0
0 Degree
Machine
List
Boom
Angle
(deg.)
Load
Radius
(ft)
80.0
79.1
78.0
76.9
75.7
74.6
73.5
72.3
71.1
70.0
68.8
66.4
64.0
61.5
58.9
56.3
53.6
50.8
47.9
44.8
41.6
38.1
34.3
30.2
Reeves
4
3
2
2
61,000 *
58,600 *
56,400 *
54,000 *
51,800 *
48,900
45,400
39,200
34,100
29,700
26,500
23,400
20,500
18,000
15,600
13,600
11,800
10,200
8,800
7,500
1 Degree
Machine
List
36,300 *
35,000 *
33,700 *
31,300 *
28,900 *
26,400 *
24,400 *
22,100 *
19,400
17,100
14,900
13,000
11,300
9,700
8,400
7,200
2 Degree
Machine
List
25,500 *
24,100 *
22,300 *
20,700 *
19,200 *
17,500 *
15,900 *
14,400 *
13,000 *
11,400 *
10,200 *
8,900 *
7,500 *
6,300 *
3 Degree
Machine
List
270' Boom
360° Rated Load (lbs)
90,100 *
89,200 *
86,800 *
83,300 *
77,000
70,800
65,300
60,400
56,200
52,300
48,700
41,900
36,300
31,600
27,600
24,300
21,200
18,400
16,000
13,900
11,900
10,100
8,600
7,200
52.8
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
230.0
0 Degree
Machine
List
Boom
Angle
(deg.)
Load
Radius
(ft)
80.0
79.5
78.5
77.4
76.3
75.2
74.1
73.0
71.9
70.7
69.6
67.3
65.0
62.6
60.2
57.7
55.2
52.5
49.8
46.9
43.9
40.8
37.4
33.7
Reeves
4
2
2
2
54,600 *
52,400 *
50,200 *
48,000 *
45,800 *
43,800 *
38,500
33,500
29,300
25,500
22,400
19,800
17,200
14,900
12,700
10,900
9,300
7,900
6,600
1 Degree
Machine
List
34,300 *
33,000 *
31,900 *
30,800 *
28,400 *
26,200 *
23,800 *
21,600 *
19,700 *
17,700 *
15,700 *
14,000 *
12,200
10,400
8,900
7,500
6,200 *
2 Degree
Machine
List
21,500 *
19,900 *
18,400 *
16,600 *
15,200 *
13,600 *
12,100 *
10,800 *
9,300 *
8,100 *
6,700 *
5,600 *
3 Degree
Machine
List
280' Boom
360° Rated Load (lbs)
82,400 *
82,200 *
80,300 *
78,200 *
74,300 *
69,400
64,000
59,300
55,100
51,200
47,700
41,500
36,000
31,200
27,400
23,800
20,800
18,000
15,600
13,500
11,400
9,600
8,200
6,700
5,500
54.4
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
230.0
240.0
0 Degree
Machine
List
Boom
Angle
(deg.)
Load
Radius
(ft)
80.0
79.9
78.9
77.8
76.8
75.7
74.7
73.6
72.5
71.4
70.4
68.2
65.9
63.7
61.4
59.0
56.6
54.1
51.5
48.8
46.0
43.1
40.0
36.7
33.1
Reeves
4
2
2
2
51,300 *
49,100 *
47,100 *
44,900 *
42,900 *
41,000 *
37,200 *
33,000
28,800
25,300
22,000
19,100
16,500
14,500
12,500
10,500
8,900
7,400
6,100
1 Degree
Machine
List
30,800 *
29,700 *
28,400 *
26,200 *
24,000 *
22,000 *
19,800 *
17,800 *
15,800 *
14,000 *
12,200 *
10,700 *
9,000 *
7,500 *
6,100 *
2 Degree
Machine
List
19,700 *
18,200 *
16,400 *
15,100 *
13,500 *
12,000 *
10,600 *
9,200 *
8,000 *
6,700 *
5,500 *
3 Degree
Machine
List
