SPECIFICATIONS
71
Clamshell
6 Counterweights (105,570 lbs) - Without Carbody weights.
38.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
66.3
64.7
60.7
56.4
52.0
47.2
42.0
36.2
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
Load
Radius
(ft)
Boom
Angle
(deg.)
360
ﾟ
Rated Load
(lbs)
80' Boom
45.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
64.2
60.6
56.8
52.9
48.7
44.3
39.4
34.0
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
Load
Radius
(ft)
Boom
Angle
(deg.)
360
ﾟ
Rated Load
(lbs)
90' Boom
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
63.8
60.5
57.2
53.7
50.0
46.1
41.9
37.3
32.2
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
Load
Radius
(ft)
Boom
Angle
(deg.)
360
ﾟ
Rated Load
(lbs)
100' Boom
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
66.4
63.5
60.5
57.4
54.3
50.9
47.5
43.8
39.8
35.5
30.6
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
27,700
25,700
Load
Radius
(ft)
Boom
Angle
(deg.)
360
ﾟ
Rated Load
(lbs)
110' Boom
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
105.0
65.8
63.2
60.5
57.6
54.8
51.7
48.6
45.3
41.8
38.0
33.9
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
29,500 *
27,900
25,700
23,800
Load
Radius
(ft)
Boom
Angle
(deg.)
360
ﾟ
Rated Load
(lbs)
120' Boom
Refer to notes on page 69.
