CK3300G-2
CRANE - WORKINGRANGES
Heavy Fixed Jib 30 deg.
236 (72) Boom + 98 (30) Jib
236 (72) Boom + 79 (24) Jib
236 (72) Boom + 59 (18) Jib
82.8 deg.
30 deg.
82.7 deg.
82.8 deg.
73.3 deg.
98 (30) Boom + 79 (24) Jib
98 (30) Boom + 98 (30) Jib
98 (30) Boom + 59 (18) Jib
70 deg.
60 deg.
50 deg.
50 deg.
60 deg.
64.2 deg.
80.4 deg.
81.3 deg.
78.1 deg.
Center
of rotation
33 (10)
33
(10)
66 (20)
Unit : ft (m)
66
(20)
98 (30)
98
(30)
131 (40)
131
(40)
164 (50)
164
(50)
197 (60)
197
(60)
230 (70)
230
(70)
263 (80)
263
(80)
295 (90)
295
(90)
328 (100)
328
(100)
360 (110)
394 (120)
Height above ground
5′ 11″
(1,800 mm)
9′ 1″
(2,780 mm)
Radius from center of rotation
• Working weight*
1
: 825,821 lbs (374,592 kg)
• Ground bearing pressure*
1
: Approx. 22.8 psi (157 kPa)
• Wind speed : 100% performance in wind speed up to 10 m/s (22.5 MPH)
*
1
: Including base machine, counterweights : 352,700 lbs (160,000 kg), Carbody weights : 88,200 lbs (40,000 kg),
Counterweight self removal device, 236 ft (72 m) standard boom, 98 ft (30 m) heavy fixed jib and 50 US ton hook block.
