STANDARDCONFIGURATION
CRANE - LIFTINGCHART
Heavy Fixed Jib Lift
Capacity
(without main hook weight deduct)
Counterweights : 352,700 lbs (160,000 kg) Carbody weights : 88,200 lbs (40,000 kg)
98 ft (30 m) Boom
59 ft jib
79 ft jib
98 ft jib
Offset Angle (deg.)
Offset Angle (deg.)
Offset Angle (deg.)
15
30
15
30
15
30
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
60.0 77.2 88,200 *
60.0 80.2 88,200 *
70.0 79.4 78,600 *
65.0 75.3 88,200 *
65.0 78.6 88,200 *
75.0 77.9 73,500 *
70.0 73.3 88,200 *
70.0 78.1 68,400 *
70.0 76.9 86,500 *
80.0 76.3 68,800 *
75.0 71.3 88,000 *
75.0 76.1 65,300 *
75.0 75.2 82,900 *
75.0 81.3 54,200 *
85.0 74.7 64,800 *
80.0 69.4 87,700 *
80.0 74.0 62,400 *
80.0 73.4 78,000 *
80.0 79.5 51,600 *
90.0 73.2 61,200 *
90.0 80.4 39,700 *
85.0 67.4 86,700 *
85.0 72.0 59,800 *
85.0 71.7 73,400 *
85.0 77.6 49,300 *
95.0 71.6 57,900 *
95.0 78.7 37,900 *
90.0 65.2 82,500 *
90.0 69.8 57,500 *
90.0 69.9 69,500 *
90.0 75.8 47,200 * 100.0 70.0 54,900 * 100.0 77.0 36,300 *
95.0 63.1 78,500 *
95.0 67.6 55,300 *
95.0 68.1 66,000 *
95.0 73.9 45,200 * 110.0 66.7 49,700 * 110.0 73.6 33,300 *
100.0 60.9 75,000 * 100.0 65.3 53,400 * 100.0 66.3 62,800 * 100.0 71.9 43,300 * 120.0 63.3 45,300 * 120.0 70.0 30,800 *
110.0 56.4 68,600 * 110.0 60.7 50,100 * 110.0 62.4 57,200 * 110.0 67.9 40,100 * 130.0 59.7 41,600 * 130.0 66.2 28,600 *
120.0 51.5 63,500 * 120.0 55.5 47,300 * 120.0 58.4 52,600 * 120.0 63.7 37,500 * 140.0 55.9 38,400 * 140.0 62.2 26,700 *
130.0 46.1 59,100 * 130.0 49.8 45,000 * 130.0 54.1 48,600 * 130.0 59.1 35,200 * 150.0 51.9 35,700 * 150.0 58.0 25,000 *
140.0 40.1 55,300 * 140.0 43.3 43,100 * 140.0 49.5 45,100 * 140.0 54.3 33,100 * 160.0 47.5 33,300 * 160.0 53.2 23,600 *
150.0 32.9 52,500 * 150.0 35.6 41,700 * 150.0 44.5 42,100 * 150.0 48.8 31,400 * 170.0 42.7 31,300 * 170.0 47.9 22,500 *
160.0 42.2 30,200 * 180.0 37.3 29,500 * 180.0 41.7 21,500 *
Reeves
3
Reeves
3
Reeves
3
Reeves
2
Reeves
3
Reeves
2
118 ft (36 m) Boom
59 ft jib
79 ft jib
98 ft jib
Offset Angle (deg.)
Offset Angle (deg.)
Offset Angle (deg.)
15
30
15
30
15
30
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
55.0 80.3 88,200 *
60.0 81.3 88,200 *
60.0 83.1 88,200 *
60.0 78.6 88,200 *
65.0 79.7 88,200 *
65.0 81.7 88,200 *
65.0 77.0 88,200 *
70.0 78.2 88,200 *
70.0 80.3 84,200 *
70.0 75.3 88,200 *
70.0 79.5 70,600 *
75.0 76.7 86,200 *
75.0 82.2 55,800 *
75.0 79.0 79,400 *
75.0 73.6 88,000 *
75.0 77.8 67,700 *
80.0 75.2 82,600 *
80.0 80.6 53,200 *
80.0 77.6 74,700 *
80.0 71.8 87,900 *
80.0 76.0 65,000 *
85.0 73.6 78,300 *
85.0 79.0 51,000 *
85.0 76.2 70,300 *
85.0 70.1 87,900 *
85.0 74.2 62,500 *
90.0 72.0 74,200 *
90.0 77.4 49,000 *
90.0 74.9 66,600 *
90.0 81.4 41,000 *
90.0 68.3 87,400 *
90.0 72.3 60,100 *
95.0 70.4 70,600 *
95.0 75.7 47,100 *
95.0 73.4 63,200 *
95.0 79.9 39,200 *
95.0 66.5 84,800 *
95.0 70.5 58,000 * 100.0 68.8 67,400 * 100.0 74.0 45,300 * 100.0 72.0 60,100 * 100.0 78.4 37,600 *
100.0 64.6 81,100 * 100.0 68.5 56,100 * 110.0 65.6 61,500 * 110.0 70.6 42,100 * 110.0 69.0 54,600 * 110.0 75.3 34,800 *
110.0 60.7 74,400 * 110.0 64.7 52,700 * 120.0 62.1 56,600 * 120.0 67.0 39,500 * 120.0 66.0 49,900 * 120.0 72.2 32,200 *
120.0 56.7 69,000 * 120.0 60.4 49,800 * 130.0 58.5 52,400 * 130.0 63.2 37,100 * 130.0 62.8 45,900 * 130.0 68.9 30,100 *
130.0 52.5 64,200 * 130.0 56.0 47,300 * 140.0 54.7 48,900 * 140.0 59.2 35,000 * 140.0 59.6 42,500 * 140.0 65.5 28,200 *
140.0 47.9 60,100 * 140.0 51.3 45,200 * 150.0 50.7 45,700 * 150.0 55.0 33,200 * 150.0 56.3 39,500 * 150.0 61.9 26,600 *
150.0 42.9 56,700 * 150.0 46.0 43,500 * 160.0 46.3 43,100 * 160.0 50.2 31,800 * 160.0 52.7 36,900 * 160.0 58.1 25,000 *
160.0 37.1 51,400
160.0 39.7 42,300 *
170.0 44.9 30,600 * 170.0 48.9 34,600 * 170.0 54.0 23,700 *
180.0 38.7 29,600 * 180.0 44.8 32,500 * 180.0 49.5 22,600 *
190.0 31.0 29,100 * 190.0 40.3 30,900 * 190.0 44.6 21,800 *
200.0 35.0 29,300 * 200.0 38.4 21,100 *
Reeves
3
Reeves
3
Reeves
3
Reeves
2
Reeves
3
Reeves
2
Note : Designed and rated to comply with ASME Code B30.5
Capacities based on factors other than machine stability such as structural competence are shown by asterisk * in the charts.
Refer to notes on 30.
