CK3300G-2

58 / 118

56
CK3300G-2
CRANE - LIFTINGCHART
Fixed Jib Lift Capacity
(without main hook weight deduct) Counterweights : 308,600 lbs (140,000 kg) Carbody weights : 88,200 lbs (40,000 kg)
177 ft (54 m) Boom
40 ft jib 60 ft jib 80 ft jib 100 ft jib
Offset Angle (deg.) Offset Angle (deg.) Offset Angle (deg.) Offset Angle (deg.)
10 30 10 30 10 30 10 30
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
49.2 80.0 58,200 * 56.4 80.0 46,500 * 63.0 80.0 26,600 * 66.9 80.0 14,900 *
50.0 79.7 58,000 * 60.0 79.1 46,000 * 65.0 79.3 26,500 * 70.0 79.1 14,700 *
55.0 78.4 57,200 * 65.0 77.9 44,800 * 70.0 78.1 25,900 * 75.0 78.0 14,500 *
60.0 77.1 55,900 * 61.1 80.0 42,300 * 70.0 76.6 43,700 * 74.9 80.0 29,700 * 75.0 77.0 25,300 * 80.0 77.0 14,000 *
65.0 75.7 54,700 * 65.0 78.9 42,000 * 75.0 75.4 42,600 * 75.0 79.7 29,700 * 80.0 75.9 24,700 * 85.0 75.9 13,600 *
70.0 74.3 53,400 * 70.0 77.5 41,300 * 80.0 74.1 41,500 * 80.0 78.4 29,700 * 85.0 74.7 24,100 * 86.5 80.0 17,800 * 90.0 74.8 13,300 *
75.0 73.0 52,100 * 75.0 76.1 40,700 * 85.0 72.8 40,500 * 85.0 77.1 29,500 * 90.0 73.6 23,500 * 90.0 78.9 17,700 * 95.0 73.8 13,000 * 96.6 80.0 9,400 *
80.0 71.7 51,000 * 80.0 74.7 39,900 * 90.0 71.6 39,600 * 90.0 75.8 29,200 * 95.0 72.4 23,000 * 95.0 77.7 17,400 * 100.0 72.7 12,600 * 100.0 79.0 9,300 *
85.0 70.2 49,800 * 85.0 73.3 38,900 * 95.0 70.3 38,800 * 95.0 74.5 28,700 * 100.0 71.2 22,600 * 100.0 76.5 17,000 * 110.0 70.5 12,000 * 110.0 76.8 9,300 *
90.0 68.9 48,700 * 90.0 71.9 37,900 * 100.0 69.0 37,900 * 100.0 73.2 28,300 * 110.0 68.8 21,700 * 110.0 74.0 16,500 * 120.0 68.3 11,400 * 120.0 74.5 8,900 *
95.0 67.4 47,700 * 95.0 70.4 36,900 * 110.0 66.5 36,400 * 110.0 70.5 27,100 * 120.0 66.4 20,700 * 120.0 71.6 16,000 * 130.0 66.0 10,800 * 130.0 72.2 8,600 *
100.0 66.0 46,700 100.0 69.0 35,900 * 120.0 63.7 35,000 * 120.0 67.7 25,900 * 130.0 64.0 19,900 * 130.0 69.0 15,600 * 140.0 63.7 10,400 * 140.0 69.8 8,300 *
110.0 63.1 44,700 110.0 66.0 34,400 * 130.0 61.0 33,200 * 130.0 64.9 24,800 * 140.0 61.4 19,200 * 140.0 66.4 15,100 * 150.0 61.4 9,900 * 150.0 67.4 8,100 *
120.0 60.1 40,900 120.0 63.0 33,100 * 140.0 58.1 31,000 140.0 62.0 23,800 * 150.0 58.8 18,300 * 150.0 63.7 14,800 * 160.0 58.9 9,600 * 160.0 64.9 8,000 *
130.0 57.0 36,200 130.0 59.8 31,600 * 150.0 55.2 29,100 150.0 59.0 22,900 * 160.0 56.1 17,900 * 160.0 60.9 14,400 * 170.0 56.5 9,200 * 170.0 62.3 7,700 *
140.0 53.8 32,200 140.0 56.5 30,600 160.0 52.2 26,600 160.0 55.8 22,000 * 170.0 53.3 17,200 * 170.0 58.0 14,100 * 180.0 53.9 8,900 * 180.0 59.7 7,600 *
150.0 50.5 28,600 150.0 53.1 29,200 170.0 49.0 24,000 170.0 52.6 21,400 * 180.0 50.4 16,600 * 180.0 55.0 14,000 * 190.0 51.2 8,600 * 190.0 56.9 7,400 *
160.0 46.9 25,700 160.0 49.5 26,300 180.0 45.7 21,700 180.0 49.1 20,800 * 190.0 47.3 16,100 * 190.0 51.8 13,600 * 200.0 48.5 8,200 * 200.0 54.0 7,200 *
170.0 43.2 23,000 170.0 45.6 23,500 190.0 42.1 19,600 190.0 45.4 20,300 * 200.0 44.1 15,700 * 200.0 48.4 13,500 * 210.0 45.5 8,100 * 210.0 50.9 7,200 *
180.0 39.1 20,800 180.0 41.4 21,100 200.0 38.2 17,700 200.0 41.2 18,600 * 210.0 40.7 15,200 * 210.0 44.8 13,400 * 220.0 42.5 7,800 * 220.0 47.7 7,000 *
190.0 34.7 18,700 190.0 36.7 19,000 210.0 33.9 16,300 210.0 36.6 16,900 220.0 37.0 14,800 * 220.0 40.9 13,200 * 230.0 39.2 7,700 * 230.0 44.2 7,000 *
199.3 30.0 17,100 200.0 31.3 17,100 218.2 30.0 14,900 220.0 31.2 15,300 230.0 32.9 14,200 * 230.0 36.5 13,200 * 240.0 35.7 7,400 * 240.0 40.5 6,900 *
202.3 30.0 16,700 221.4 30.0 14,900 237.5 30.0 13,400 * 240.0 31.2 13,200 250.0 31.8 7,200 * 250.0 36.1 6,500
243.2 30.0 13,200 255.1 30.0 7,000 * 260.0 31.1 6,200
263.0 30.0 6,100
Reeves 2 Reeves 2 Reeves 2 Reeves 1 Reeves 1 Reeves 1 Reeves 1 Reeves 1
197 ft (60 m) Boom
40 ft jib 60 ft jib 80 ft jib 100 ft jib
Offset Angle (deg.) Offset Angle (deg.) Offset Angle (deg.) Offset Angle (deg.)
10 30 10 30 10 30 10 30
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
Load
Radius
(ft)
Boom
Angle
(deg.)
Rated
Load
(lbs)
54.4 80.0 58,400 * 59.8 80.0 46,500 * 66.4 80.0 26,600 * 70.3 80.0 14,700 *
55.0 79.3 58,200 * 60.0 79.9 46,400 * 70.0 79.0 26,300 * 75.0 78.9 14,600 *
60.0 78.1 56,800 * 64.5 80.0 42,300 * 65.0 78.8 45,700 * 75.0 77.9 25,800 * 80.0 77.9 14,200 *
65.0 76.9 55,500 * 65.0 79.9 42,200 * 70.0 77.6 44,500 * 80.0 76.9 25,200 * 85.0 76.9 13,900 *
70.0 75.7 54,500 * 70.0 78.6 41,800 * 75.0 76.5 43,400 * 78.3 80.0 29,700 * 85.0 75.8 24,600 * 89.9 80.0 17,800 * 90.0 75.9 13,500 *
75.0 74.5 53,400 * 75.0 77.3 41,200 * 80.0 75.4 42,400 * 80.0 79.3 29,700 * 90.0 74.7 24,100 * 90.0 79.7 17,700 * 95.0 74.9 13,200 *
80.0 73.2 52,000 * 80.0 76.0 40,600 * 85.0 74.2 41,500 * 85.0 78.1 29,700 * 95.0 73.7 23,700 * 95.0 78.6 17,600 * 100.0 73.9 12,900 * 100.1 80.0 9,400 *
85.0 71.9 51,000 * 85.0 74.7 40,000 * 90.0 73.1 40,500 * 90.0 77.0 29,400 * 100.0 72.6 23,200 * 100.0 77.5 17,300 * 110.0 71.9 12,200 * 110.0 77.7 9,300 *
90.0 70.7 50,000 * 90.0 73.4 39,000 * 95.0 71.9 39,600 * 95.0 75.8 29,100 * 110.0 70.4 22,200 * 110.0 75.3 16,800 * 120.0 69.8 11,700 * 120.0 75.6 8,900 *
95.0 69.4 49,000 * 95.0 72.1 38,000 * 100.0 70.7 38,800 * 100.0 74.6 28,700 * 120.0 68.2 21,400 * 120.0 73.0 16,200 * 130.0 67.7 11,200 * 130.0 73.4 8,800 *
100.0 68.1 48,000 100.0 70.8 37,000 * 110.0 68.3 37,300 * 110.0 72.1 27,900 * 130.0 65.9 20,500 * 130.0 70.7 15,900 * 140.0 65.6 10,700 * 140.0 71.3 8,500 *
110.0 65.5 45,000 110.0 68.2 35,400 * 120.0 65.9 35,900 * 120.0 69.7 26,700 * 140.0 63.6 19,800 * 140.0 68.3 15,500 * 150.0 63.4 10,300 * 150.0 69.1 8,300 *
120.0 62.8 39,800 120.0 65.4 33,900 * 130.0 63.5 34,700 * 130.0 67.1 25,500 * 150.0 61.3 19,000 * 150.0 65.9 15,000 * 160.0 61.3 9,800 * 160.0 66.8 8,000 *
130.0 60.1 35,000 130.0 62.7 32,700 * 140.0 60.9 31,900 140.0 64.5 24,500 * 160.0 58.8 18,400 * 160.0 63.4 14,600 * 170.0 59.0 9,400 * 170.0 64.5 7,900 *
140.0 57.2 31,100 140.0 59.8 31,200 150.0 58.3 28,600 150.0 61.8 23,600 * 170.0 56.3 17,800 * 170.0 60.8 14,500 * 180.0 56.7 9,100 * 180.0 62.1 7,700 *
150.0 54.3 27,500 150.0 56.8 28,300 160.0 55.6 25,600 160.0 59.1 22,800 * 180.0 53.8 17,300 * 180.0 58.2 14,200 * 190.0 54.3 8,800 * 190.0 59.6 7,500 *
160.0 51.2 24,400 160.0 53.6 25,300 170.0 52.8 22,800 170.0 56.2 22,000 * 190.0 51.1 16,700 * 190.0 55.4 13,800 * 200.0 51.8 8,500 * 200.0 57.1 7,300 *
170.0 48.0 21,900 170.0 50.4 22,600 180.0 49.9 20,500 180.0 53.2 21,400 * 200.0 48.3 16,300 * 200.0 52.5 13,700 * 210.0 49.3 8,300 * 210.0 54.4 7,200 *
180.0 44.7 19,700 180.0 47.0 20,200 190.0 46.8 18,500 190.0 50.0 19,600 * 210.0 45.4 15,800 * 210.0 49.4 13,600 * 220.0 46.6 8,000 * 220.0 51.6 7,200 *
190.0 41.2 17,600 190.0 43.3 18,100 200.0 43.6 16,600 200.0 46.6 17,700 220.0 42.3 14,700 * 220.0 46.2 13,400 * 230.0 43.9 7,900 * 230.0 48.7 7,000 *
200.0 37.2 15,700 200.0 39.2 16,200 210.0 40.1 14,800 210.0 43.0 16,000 230.0 39.0 13,100 230.0 42.7 13,200 * 240.0 40.9 7,700 * 240.0 45.6 7,000 *
210.0 32.9 14,200 210.0 34.7 14,400 220.0 36.4 13,600 220.0 39.1 14,400 240.0 35.4 11,900 240.0 38.9 12,400 250.0 37.7 7,400 * 250.0 42.2 7,000 *
216.3 30.0 13,200 219.3 30.0 13,000 230.0 32.3 12,100 230.0 34.7 12,900 250.0 31.5 10,900 250.0 34.6 11,000 260.0 34.3 7,300 * 260.0 38.5 6,600
235.3 30.0 11,400 240.0 30.2 11,600 254.5 30.0 10,300 260.0 30.1 10,100 270.0 30.5 7,100 * 270.0 34.4 6,300
240.3 30.0 11,600 260.2 30.0 10,100 272.2 30.0 6,600 * 280.1 30.0 5,900
Reeves 2 Reeves 2 Reeves 2 Reeves 1 Reeves 1 Reeves 1 Reeves 1 Reeves 1
In case of 40 ft (12.2 m) jib length with offset angle 10 degrees and one part of line on hook, additional parts required-contract KOBELCO CONSTRUCTION MACHINERY U.S.A. INC.
Note : Designed and rated to comply with ASME Code B30.5
Capacities based on factors other than machine stability such as structural competence are shown by asterisk * in the charts.
Refer to notes on 27 to 29.
