SPECIFICATIONS
59
Fixed Jib Lift Capacity (with 165 US ton / 110 US ton main hook)
Full Counterweight: 200,650 lbs CarbodyWeight: 60,240
Note: Designed and rated to comply with ANSI Code B30.5
Capacities based on factors other than machine stability such as structural competence are shown by asterisk * in the charts.
Refer to notes on page 21.
250' Boom
30
10
30
10
40 ft Jib
O set Angle (deg.)
80 ft Jib
O set Angle (deg.)
29,700*
29,700*
29,600*
29,400*
28,900*
28,300*
27,200*
26,200*
25,400*
23.100*
18,900*
16,500
13,900
11,700
9,900
8,200
6,700
5,300
4,100
2,900
2,600
86.9
90.0
95.0
100.0
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
230.0
240.0
250.0
260.0
262.4
Rated
Load
(lbs)
Boom
Angle
(deg.)
Load
Radius
(ft)
80.0
79.4
78.4
77.4
75.4
73.4
71.4
69.3
67.2
65.1
62.8
60.6
58.3
55.9
53.4
50.8
48.1
45.2
42.2
38.9
38.0
46,500*
46,200*
45,200*
44,300*
43,400*
42,600*
41,800*
41,000*
39,600*
36,800*
29,900
26,000
22,300
19,300
16,400
13,800
11,700
9,800
8,100
6,600
5,200
4,100
3,000
68.9
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
230.0
240.0
249.3
Rated
Load
(lbs)
Boom
Angle
(deg.)
Load
Radius
(ft)
80.0
79.8
78.8
77.9
76.9
76.0
75.0
74.1
72.1
70.2
68.2
66.1
64.1
62.0
59.8
57.6
55.4
53.0
50.6
48.1
45.5
42.8
40.1
42,100*
42,000*
41,500*
41,200*
40,700*
40,100*
39,400*
37,700*
33,500
30,300
26,000
22,300
19,300
16,200
13,600
11,300
9,300
7,700
6,000
4,500
3,300
3,000
74.1
75.0
80.0
85.0
90.0
95.0
100.0
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
230.0
240.0
242.7
Rated
Load
(lbs)
Boom
Angle
(deg.)
Load
Radius
(ft)
80.0
79.8
78.8
77.7
76.7
75.7
74.6
72.5
70.3
68.1
65.9
63.6
61.2
58.8
56.4
53.8
51.1
48.4
45.4
42.3
39.0
38.0
58,200*
57,600*
56,600*
55,600*
54,400*
52,700*
51,100*
47,600
43,500
37,800
33,000
28,300
24,500
21,000
17,900
14,900
12,300
10,400
8,600
7,000
5,500
4,100
3,000
2,600
62.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
230.0
240.0
242.7
Rated
Load
(lbs)
Boom
Angle
(deg.)
Load
Radius
(ft)
80.0
79.4
78.4
77.4
76.8
75.4
74.3
73.3
72.3
70.2
68.0
65.9
63.7
61.4
59.1
56.8
54.4
51.9
49.3
46.6
43.7
40.7
37.5
36.6
30
10
30
10
9,400*
9,200*
9,000*
8,700*
8,500*
8,300*
8,100*
8,000*
7,700*
7,700*
7,400*
7,300*
7,200*
7,200*
7,200*
6,600*
5,500*
3,700*
2,600
112.5
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
230.0
240.0
250.0
260.0
270.0
280.0
288.7
Rated
Load
(lbs)
Boom
Angle
(deg.)
Load
Radius
(ft)
80.0
78.7
76.9
75.1
73.3
71.4
69.5
67.6
65.6
63.6
61.5
59.4
57.2
54.9
52.6
50.1
47.6
44.8
42.3
14,700*
14,500*
14,200*
13,800*
13,500*
13,000*
12,500*
11,900*
11,500*
11,000*
10,700*
10,300*
9,800*
9,700*
9,300*
9,000*
8,700*
8,500*
7,600*
6,300*
4,600*
3,200
2,600
82.6
85.0
90.0
95.0
100.0
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
230.0
240.0
250.0
260.0
270.0
275.5
Rated
Load
(lbs)
Boom
Angle
(deg.)
Load
Radius
(ft)
80.0
79.6
78.8
77.9
77.1
75.4
73.6
71.9
70.1
68.4
66.5
64.7
62.8
60.9
59.0
57.0
55.0
52.9
50.7
48.5
46.1
43.7
42.3
17,600*
17,600*
17,200*
16,800*
16,300*
16,000*
15,600*
15,300*
15,000*
14,700*
14,500*
14,200*
12,700*
10,000
8,100
6,700
5,400
4,200
3,200
2,600
99.7
100.0
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
230.0
240.0
250.0
260.0
270.0
275.5
Rated
Load
(lbs)
Boom
Angle
(deg.)
Load
Radius
(ft)
80.0
79.9
78.1
76.2
74.3
72.4
70.4
68.4
66.4
64.3
62.2
60.0
57.7
55.4
53.0
50.5
47.8
45.0
42.0
40.3
26,400*
26,100*
25,600*
25,000*
24,700*
24,300*
23,400*
22,500*
21,900*
21,200*
20,500*
19,800*
19,200*
18,100*
14,800*
11,700
9,600
8,100
6,900
5,500
4,300
3,300
3,000
75.7
80.0
85.0
90.0
95.0
100.0
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
230.0
240.0
250.0
260.0
262.4
Rated
Load
(lbs)
Boom
Angle
(deg.)
Load
Radius
(ft)
80.0
79.2
78.3
77.5
76.6
75.7
73.8
72.0
70.1
68.3
66.4
64.4
62.4
60.4
58.4
56.2
54.1
51.8
49.5
47.1
44.6
41.9
41.2
60 ft Jib
O set Angle (deg.)
100 ft Jib
O set Angle (deg.)
Reeves
2 Reeves
2 Reeves
2 Reeves
1 Reeves
1 Reeves
1 Reeves
1 Reeves
1
