Lu ng Boom/Jib - SPECIFICATIONS
171
Lu ng Jib Lift Capacities
Full Counterweights (200,650 lbs) - Carbody weights (60,240 lbs)
Refer to notes on page 88- 89.
190' Boom
83
78
73
68
63
88
83
78
73
68
63
88
200 ft Jib
Boom Angle (deg.)
190 ft Jib
Boom Angle (deg.)
35,900*
35,600*
35,200*
34,900*
34,600*
34,100*
32,100*
29,800*
27,800*
25,800*
24,100*
22,500*
20,000*
16,400*
13,300*
Rated
Load
(lbs)
Load
Radius
(ft)
75.0
80.0
85.0
90.0
95.0
100.0
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
33,700*
31,000*
28,900*
26,800*
25,000*
23,300*
21,900*
20,500*
18,700*
17,100*
Rated
Load
(lbs)
Load
Radius
(ft)
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
27,700*
25,900*
24,000*
22,500*
20,600*
19,000*
17,500*
15,800*
14,100*
Rated
Load
(lbs)
Load
Radius
(ft)
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
21,900
20,200
18,500
17,200
15,800
14,500*
13,100*
11,600*
Rated
Load
(lbs)
Load
Radius
(ft)
170.0
180.0
190.0
200.0
210.0
220.0
230.0
240.0
14,500
13,200
12,200
11,200
10,300
9,400
8,700
Rated
Load
(lbs)
Load
Radius
(ft)
200.0
210.0
220.0
230.0
240.0
250.0
260.0
8,700
8,100
7,400
6,700
6,100
Rated
Load
(lbs)
Load
Radius
(ft)
230.0
240.0
250.0
260.0
270.0
32,600*
32,300*
31,900*
31,600*
31,300*
30,800*
29,000*
26,900*
25,100*
23,400*
21,900*
20,600*
18,000*
14,400*
11,100*
8,100*
Rated
Load
(lbs)
Load
Radius
(ft)
75.0
80.0
85.0
90.0
95.0
100.0
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
30,500*
28,200*
26,000*
24,300*
22,600*
21,200*
19,900*
18,600*
17,600*
16,000*
12,700*
9,100*
Rated
Load
(lbs)
Load
Radius
(ft)
110.0
120.0
130.0
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
25,200*
23,500*
21,900*
20,300*
19,200*
18,100*
16,800*
15,400*
13,900*
12,500*
Rated
Load
(lbs)
Load
Radius
(ft)
140.0
150.0
160.0
170.0
180.0
190.0
200.0
210.0
220.0
230.0
19,500*
18,100*
16,700*
15,400*
14,000*
12,700*
11,300*
10,000*
Rated
Load
(lbs)
Load
Radius
(ft)
180.0
190.0
200.0
210.0
220.0
230.0
240.0
250.0
12,700
11,700
10,700
9,900
9,100
8,300
Rated
Load
(lbs)
Load
Radius
(ft)
210.0
220.0
230.0
240.0
250.0
260.0
8,500
7,600
7,000
6,300
Rated
Load
(lbs)
Load
Radius
(ft)
230.0
240.0
250.0
260.0
Reeves 2 Reeves 2 Reeves 2 Reeves 2 Reeves 2 Reeves 2 Reeves 2 Reeves 2 Reeves 2 Reeves 2 Reeves 2 Reeves 2
